Panasonic TX-29PN1D - Page 16

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CAPC2317 ECJ2VF1H224Z 50V 220nF
S.M.CAPC2319 ECJ2VF1H224Z 50V 220nF
S.M.CAPC2320 ECJ2VC1H102J 50V 1nF
S.M.CAPC2321 ECJ2VC1H102J 50V 1nF
S.M.CAPC2322 ECJ2VC1H102J 50V 1nF
S.M.CAPC2323 ECJ2VC1H102J 50V 1nF
S.M.CAPC2329 ECJ2VC1H102J 50V 1nF
S.M.CAPC2350 ECJ2VF1H224Z 50V 220nF
S.M.CAPC2351 ECJ2VF1H224Z 50V 220nF
S.M.CAPC2352 ECJ2VF1H224Z 50V 220nF
S.M.CAPC2353 ECJ2VF1H224Z 50V 220nF
S.M.CAPC2407 ECJ2VF1C105Z 16V 1µF
S.M.CAPC2411 ECJ2VF1C105Z 16V 1µF
S.M.CAPC2412 ECJ2VF1C105Z 16V 1µF
ELECTC2414 F2A1C100A180 16V 10µF
S.M.CAPC2416 ECJ2VF1C105Z 16V 1µF
S.M. CAPC2417 ECUV1H104KBX 50V 100nF
FILM C2418 ECQB1H153K 50V 15nF
S.M.CAPC3005 ECJ2VC1H331J 50V 330pF
S.M. CAPC3006 ECUV1H561KBX 50V 560pF
S.M. CAPC3007 ECUV1H561KBX 50V 560pF
S.M.CAPC3008 ECJ2VC1H331J 50V 330pF
S.M.CAPC3010 ECJ2VC1H331J 50V 330pF
S.M.CAPC3012 ECJ2VC1H331J 50V 330pF
S.M.CAPC3019 ECJ2VC1H331J 50V 330pF
S.M.CAPC3026 ECJ2VC1H331J 50V 330pF
S.M.CAPC3028 ECUV1H101JCG 50V 100pF
S.M.CAPC3029 ECUV1H101JCG 50V 100pF
S.M. CAPC3030 ECUV1H561KBX 50V 560pF
S.M.CAPC3031 ECJ2VC1H331J 50V 330pF
S.M. CAPC3032 ECUV1H561KBX 50V 560pF
S.M.CAPC3033 ECJ2VC1H331J 50V 330pF
S.M.CAPC3136 ECUV1H103JCN 50V 10nF
S.M.CAPC3137 ECUV1H103JCN 50V 10nF
ELECTC3138 F2A1C101A180 16V 100µF
ELECTC3139 F2A1C101A180 16V 100µF
S.M. CAPC3143 ECUV1H561KBX 50V 560pF
S.M. CAPC3144 ECUV1H561KBX 50V 560pF
S.M. CAPC3145 ECUV1H561KBX 50V 560pF
S.M. CAPC3146 ECUV1H561KBX 50V 560pF
TERMINALS AND LINKS
21PIN TERMINAL JK3001 0350808500
A.V. TERMINAL JK3201 TJB16673
CRT SOCKET SC351 0330550049
SWITCHES
SWITCH SW840 ESB92S11B
SWITCH SW1011 EVQ11G05R
SWITCH SW1012 EVQ11G05R
SWITCH SW1013 EVQ11G05R
SWITCH SW1014 EVQ11G05R
SWITCH SW1015 EVQ11G05R
RELAYS
RELAY RL801 8-1419125-3
DIFFERENCES FOR MODEL TX--28PN1D
EXPLODED VIEW
AC CORD ASSY 13 TXASX01ABLE
BACK COVER 14 TKU0E0140
C.R.T. 15 W66MAF185X03
CABINET 16 TKY0E0151
D P.C.B. 17 D-28PN1D
DEGAUSS COIL 18 TLK0E9023
MODEL LABEL 19 TBM0E0422
MISCELLANEOUS COMPONENTS
CARTON . TPC0E46001
BOTTOM CUSHION . TPD0E0066
TOP CUSHION . TPD0E0067
INSTRUCTION BOOKS
GERMAN . TQB0E0149A-M
ITALIAN . TQB0E0149C-M
FRENCH . TQB0E0149D-M
I.C.s
EAROM 24C32ANSU27TIC1103 GP4L/2A06D
DIODES
DIODE D511 MA4200LTA
COILS
COIL L557 ELH5L6164
COIL L704 ELC10D123E
RESISTORS
S.M.CARBR404 ERJ6GEYJ183 0.1W 5% 18K Ω
METALR407 ERG1SJ331 1W 5% 330 Ω
S.M.CARBR413 ERJ6GEYJ183 0.1W 5% 18K Ω
METAL R506 ERG1SJ101 1W 5% 100 Ω
METALR508 ERG1SJ470P 1W 5% 47 Ω
FUSIBLER556 ERQ12AJ151P 0.5W 5% 150 Ω
METALR810 ERG2FJ120 2W 5% 12 Ω
CAPACITORS
FILMC553 ECWF2155JSB 250V 1.5µF
FILMC554 ECWF2334JSB 250V 330nF
FILMC559 ECWH16622JVB 1.6KV 6.2nF
FILM C560 ECQF4273JZH 400V 27nF
FILMC569 ECWH16472JVB 1600V 4.7nF
CERAMIC C821 ECKC3D681J 2KV 680pF
DIFFERENCES FOR MODEL TX--28PN1F
EXPLODED VIEW
AC CORD ASSY 13 TXASX01ABLE
BACK COVER 14 TKU0E0140
C.R.T. 15 W66MAF185X03
CABINET 16 TKY0E0151
D P.C.B. 17 D-28PN1F
DEGAUSS COIL 18 TLK0E9023
MODEL LABEL 19 TBM0E0421
MISCELLANEOUS COMPONENTS
CARTON . TPC0E46001
BOTTOM CUSHION . TPD0E0066
TOP CUSHION . TPD0E0067
INSTRUCTION BOOKS
GERMAN . TQB0E0148A-M
DUTCH . TQB0E0148B-M
FRENCH . TQB0E0148D-M
SPANISH . TQB0E0148E-M
SWEDISH . TQB0E0148F-M
NORWAY . TQB0E0148G-M
FINNISH . TQB0E0148H-M
PORTUGUESE . TQB0E0148J-M
DANISH . TQB0E0148K-M
I.C.s
EAROM 24C32ANSU27TIC1103 GP4L/2A06F
DIODES
DIODE D511 MA4200LTA
COILS
COIL L557 ELH5L6164
16
