DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COIL L704 ELC10D123E
RESISTORS
S.M.CARBR404 ERJ6GEYJ183 0.1W 5% 18K Ω
METALR407 ERG1SJ331 1W 5% 330 Ω
S.M.CARBR413 ERJ6GEYJ183 0.1W 5% 18K Ω
METAL R506 ERG1SJ101 1W 5% 100 Ω
METALR508 ERG1SJ470P 1W 5% 47 Ω
FUSIBLER556 ERQ12AJ151P 0.5W 5% 150 Ω
METALR810 ERG2FJ120 2W 5% 12 Ω
CAPACITORS
FILMC553 ECWF2155JSB 250V 1.5µF
FILMC554 ECWF2334JSB 250V 330nF
FILMC559 ECWH16622JVB 1.6KV 6.2nF
FILM C560 ECQF4273JZH 400V 27nF
FILMC569 ECWH16472JVB 1600V 4.7nF
CERAMIC C821 ECKC3D681J 2KV 680pF
DIFFERENCES FOR MODEL TX--28PN1P
EXPLODED VIEW
AC CORD ASSY 13 TXASX01ABLE
BACK COVER 14 TKU0E0140
C.R.T. 15 W66MAF185X03
CABINET 16 TKY0E0151
D P.C.B. 17 D-28PN1P
DEGAUSS COIL 18 TLK0E9023
MODEL LABEL 19 TBM0E0423
MISCELLANEOUS COMPONENTS
CARTON . TPC0E46001
BOTTOM CUSHION . TPD0E0066
TOP CUSHION . TPD0E0067
INSTRUCTION BOOKS
BULGARIAN . TQB0E0150M-M
ROMANIAN . TQB0E0150N-M
POLISH . TQB0E0150P-M
HUNGARIAN . TQB0E0150Q-M
CZECH . TQB0E0150R-M
ENGLISH . TQB0E0150U-M
SLOVAKIAN . TQB0E0150W-M
I.C.s
EAROM 24C32ANSU27TIC1103 GP4L/2A06P
DIODES
DIODE D511 MA4200LTA
COILS
COIL L557 ELH5L6164
COIL L704 ELC10D123E
RESISTORS
S.M.CARBR404 ERJ6GEYJ183 0.1W 5% 18K Ω
METALR407 ERG1SJ331 1W 5% 330 Ω
S.M.CARBR413 ERJ6GEYJ183 0.1W 5% 18K Ω
METAL R506 ERG1SJ101 1W 5% 100 Ω
METALR508 ERG1SJ470P 1W 5% 47 Ω
FUSIBLER556 ERQ12AJ151P 0.5W 5% 150 Ω
METALR810 ERG2FJ120 2W 5% 12 Ω
CAPACITORS
FILMC553 ECWF2155JSB 250V 1.5µF
FILMC554 ECWF2334JSB 250V 330nF
FILMC559 ECWH16622JVB 1.6KV 6.2nF
FILM C560 ECQF4273JZH 400V 27nF
FILMC569 ECWH16472JVB 1600V 4.7nF
CERAMIC C821 ECKC3D681J 2KV 680pF
DIFFERENCES FOR MODEL TX--29PN1D
EXPLODED VIEW
AC CORD ASSY 13 TXASX01AAXE
BACK COVER 14 TKU0E0141
C.R.T. 15 A68EPD10X30
CABINET 16 TKY0E0152
D P.C.B. 17 D-29PN1D
DEGAUSS COIL 18 TLK8E05210
MODEL LABEL 19 TBM0E0425
MISCELLANEOUS COMPONENTS
CARTON . TPC0E45301
BOTTOM CUSHION . TPD0E0068
TOP CUSHION . TPD0E0069
INSTRUCTION BOOKS
GERMAN . TQB0E0152A-M
ITALIAN . TQB0E0152C-M
FRENCH . TQB0E0152D-M
I.C.s
EAROM 24C32ANSU27TIC1103 GP4L/3A06D
DIODES
DIODE D511 MA4200MTA
COILS
COIL L557 ELH5L6118
COIL L704 ELC18B123L
COIL T804 ETQR36T002A
RESISTORS
S.M.CARBR404 ERJ6GEYJ273 0.1W 5% 27K Ω
METAL R407 ERG1SJ221P 1W 5% 220 Ω
S.M.CARBR413 ERJ6GEYJ273 0.1W 5% 27K Ω
METALR506 ERG1SJ470P 1W 5% 47 Ω
METALR508 ERG1SJ680 1W 5% 68 Ω
FUSIBLE R556 ERQ12AJ101 0.5W 5% 100 Ω
METALR810 ERG2FJ470H 2W 5% 47 Ω
CAPACITORS
FILMC553 ECWF2135JSB 250V 1.3µF
FILMC554 ECWF2564JBB 250V 560nF
FILMC559 ECWH16562JVB 1K6V 5.6nF
FILMC560 ECQM4223KC 400V 220nF
FILMC569 ECWH16822JVB 1600V 8.2nF
CERAMIC C821 ECKC3D102J 2KV 1nF
DIFFERENCES FOR MODEL TX--29PN1F
EXPLODED VIEW
AC CORD ASSY 13 TXASX01AAXE
BACK COVER 14 TKU0E0141
C.R.T. 15 A68EPD10X30
CABINET 16 TKY0E0152
D P.C.B. 17 D-29PN1F
DEGAUSS COIL 18 TLK8E05210
MODEL LABEL 19 TBM0E0424
MISCELLANEOUS COMPONENTS
CARTON . TPC0E45301
BOTTOM CUSHION . TPD0E0068
TOP CUSHION . TPD0E0069
INSTRUCTION BOOKS
GERMAN . TQB0E0151A-M
DUTCH . TQB0E0151B-M
FRENCH . TQB0E0151D-M
SPANISH . TQB0E0151E-M
