Panasonic TX-29PN1D - Page 18

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
SWEDISH . TQB0E0151F-M
NORWEGIAN . TQB0E0151G-M
FINNISH . TQB0E0151H-M
DANISH . TQB0E0151K-M
I.C.s
EAROM 24C32ANSU27TIC1103 GP4L/3A06F
DIODES
DIODE D511 MA4200MTA
COILS
COIL L557 ELH5L6118
COIL L704 ELC18B123L
COIL T804 ETQR36T002A
RESISTORS
S.M.CARBR404 ERJ6GEYJ273 0.1W 5% 27K Ω
METAL R407 ERG1SJ221P 1W 5% 220 Ω
S.M.CARBR413 ERJ6GEYJ273 0.1W 5% 27K Ω
METALR506 ERG1SJ470P 1W 5% 47 Ω
METALR508 ERG1SJ680 1W 5% 68 Ω
FUSIBLE R556 ERQ12AJ101 0.5W 5% 100 Ω
METALR810 ERG2FJ470H 2W 5% 47 Ω
CAPACITORS
FILMC553 ECWF2135JSB 250V 1.3µF
FILMC554 ECWF2564JBB 250V 560nF
FILMC559 ECWH16562JVB 1K6V 5.6nF
FILMC560 ECQM4223KC 400V 220nF
FILMC569 ECWH16822JVB 1600V 8.2nF
CERAMIC C821 ECKC3D102J 2KV 1nF
DIFFERENCES FOR MODEL TX--29PN1P
EXPLODED VIEW
AC CORD ASSY 13 TXASX01AAXE
BACK COVER 14 TKU0E0141
C.R.T. 15 A68EPD10X30
CABINET 16 TKY0E0152
D P.C.B. 17 D-29PN1P
DEGAUSS COIL 18 TLK8E05210
MODEL LABEL 19 TBM0E0426
MISCELLANEOUS COMPONENTS
CARTON . TPC0E45301
BOTTOM CUSHION . TPD0E0068
TOP CUSHION . TPD0E0069
INSTRUCTION BOOKS
BULGARIAN . TQB0E0153M-M
ROMANIAN . TQB0E0153N-M
POLISH . TQB0E0153P-M
HUNGARIAN . TQB0E0153Q-M
CZECH . TQB0E0153R-M
ENGLISH . TQB0E0153U-M
SLOVAKIAN . TQB0E0153W1M
I.C.s
EAROM 24C32ANSU27TIC1103 GP4L/3A06P
DIODES
DIODE D511 MA4200MTA
COILS
COIL L557 ELH5L6118
COIL L704 ELC18B123L
COIL T804 ETQR36T002A
RESISTORS
S.M.CARBR404 ERJ6GEYJ273 0.1W 5% 27K Ω
METAL R407 ERG1SJ221P 1W 5% 220 Ω
S.M.CARBR413 ERJ6GEYJ273 0.1W 5% 27K Ω
METALR506 ERG1SJ470P 1W 5% 47 Ω
METALR508 ERG1SJ680 1W 5% 68 Ω
FUSIBLE R556 ERQ12AJ101 0.5W 5% 100 Ω
METALR810 ERG2FJ470H 2W 5% 47 Ω
CAPACITORS
FILMC553 ECWF2135JSB 250V 1.3µF
FILMC554 ECWF2564JBB 250V 560nF
FILMC559 ECWH16562JVB 1K6V 5.6nF
FILMC560 ECQM4223KC 400V 220nF
FILMC569 ECWH16822JVB 1600V 8.2nF
CERAMIC C821 ECKC3D102J 2KV 1nF
18
