Panasonic TX-32LX70F - Important Safety Notice; Replacement Parts List

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type number to your order.
Replacement Parts List
Important Safety Notice
The marking (RTL) indicates that the Retention Time is Limited for this item. After the
discontinuation of this assembly in production, the item will continue to be available for
a specific period of time. The retention period of availability is dependent on the type of
assembly, and in accordance with the laws governing part and product retention. After
the end of this period, the assembly will no longer be available.
RTL (Retention Time Limited)
Note:
X
The marking (X) indicates that board should be exchanged for service.
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
SPEAKER 1 EAS12S11F
TUNER 2 ENGF7701GF
REMOTE CONTROL 3 EUR7651120
CONTROL PANEL ASSY 4 K0RB00500006
80P CONNECTOR COVER 5 K1ZZ00001424
PANASONIC BADGE 6 TBMA216
CLAMPER BRACKET 7 TKK0E9522
CONNECTOR COVER 8 TKP0E16001
AV3 BRACKET 9 TKP0E17101
HDMI COVER 10 TKP0E21601
VESA METAL 11 TKZ0E9420
TUNER BRACKET 12 TMW0E109
P P.C.B. RTL 13 TNPA4116AA
AP P.C.B. RTL 14 TNPA4117AA
G P.C.B. RTL 15 TNPA4118AA
V P.C.B. RTL 16 TNPA4127AD
K P.C.B. RTL 17 TNPA4128AA
H P.C.B. RTL 18 TNPA4291DD
POWER BUTTON ASSY 19 TTP0E0015
MISCELLANEOUS COMPONENTS
BATTERY . R6RC/2P
AV3 LABEL . TBM0E0771
REAR AV LABEL . TBM0E0821
REAR AV LABEL/HDMI. TBM0E0834
IR WINDOW . TKP0E17904
HDMI COVER BARRIER. TMK0E940
SCREW . XSN3+6FJ
SCREW . XTB4+18JFJK
SCREW . XTV3+10JFJK
SCREW . XTV3+12JFJK
SCREW . XTW3+12TFJ
SCREW . XTWT4+Z15DFJ
SCREW . XYN4+F6FJ
SCREW PEDESTAL . XYN4+J10FJK
FERRITE CORE FC01 J0KG00000011
I.C.s
MAIN PS CONTROL IC801 C0DABYY00008
REGULATOR IC802 C0DAAMA00003
MICRO_GENX4 IC1100 MNZSFD7GP42
EEPROM BR24L08F-WE2IC1101 C3EBFC000042
REGULATOR IC2008 C0CBCBE00001
REGULATOR IC2010 C0CBCBC00190
OPERATIONAL AMPLIFIERIC2011 C0ABBB000230
AUDIO AMPLIFIER IC2012 C1BB00000947
REGULATOR IC2013 C0DBGYY00281
AUDIO PROCESSOR IC2106 C1AB00002746
1.8V REGULATOR IC2107 C0DBFFD00003
AUDIO AMPLIFIER IC2301 C1AB00002730
REGULATOR IC2303 C0DBGYY00202
REGULATOR IC2610 C0DBAJB00004
VIDEO SWITCH IC3001 AN15876A-VT
AUDIO SWITCH IC3101 AN15862A-VT
HQ1L_IC IC4200 C1AB00002727
DDR SDRAM IC4201 C3ABQJ000055
REGULATOR IC4202 C0DBAMH00018
2.5V REGULATOR IC4203 C0DBEHG00006
REGULATOR IC4204 C0CBCBC00190
REGULATOR IC4205 C0CBCAC00269
REGULATOR IC4206 C0CBCAC00269
DUAL LVDS DRIVER IC4207 C0JBCZ000556
REGULATOR IC4208 C0CBCBD00043
EEPROM M24C64-WMN6TPIC4209 C3EBJC000055
2KBIT EEPROM IC4500 C3EBDC000067
2KBIT EEPROM IC4501 C3EBDC000067
HDMI SWITCH IC4503 C1AB00002641
EEPROM M24C04-RMN6TPIC4504 C3EBEY000009
REGULATOR IC4506 C0DBGGF00001
REGULATOR IC4507 C0CBCBC00190
REGULATOR IC4508 C0CBCAD00082
REGULATOR IC4509 C0CBCAD00082
VIDEO DECODER IC4510 C1AB00002753
LEVEL SHIFTER IC4513 C0JBAU000034
LEVEL SHIFTER IC4514 C0JBAU000034
COMPARATOR IC4515 C0BBBA000024
DC/DC CONVERTER IC5600 C0DBAYY00273
DC/DC CONVERTER IC5601 C0DBAYY00274
RESET IC IC5660 C0EBM0000026
REGULATOR IC5670 C0CBCBC00190
RESET IC IC5671 C0EBF0000376
REGULATOR IC7301 C0DAAZH00025
REGULATOR IC7401 C0DAAZH00026
REGULATOR IC7501 C0DAAZH00026
REGULATOR IC7601 C0DAAZG00014
REGULATOR IC7701 C0DAAZG00014
PEAKS LITE 2 IC8001 MN2WS0039A
DDR SDRAM IC8002 C3ABRG000080
DDR SDRAM IC8003 C3ABRG000080
CLK GEN IC8004 C0ZBZ0001030
16MB FLASH IC8554 TVRP526-1
LOGIC IC IC8621 C0JBAZ002845
