Panasonic TX-32PM1 - Alignment Settings

ALIGNMENT SETTINGS
(The figures below are nominal and used for representative purposes only.)
1. Set the Bass to maximum position, set the Treble to minimum position, set the Volume to minimum then press the
down button (-/v) on the customer controls at the front of the TV and at the same time press the INDEX button on the
remote control, this will place the TV into the Service Mode 1.
2. Press the RED / GREEN buttons to step up / down through the functions.
3. Press the YELLOW / BLUE buttons to alter the function values.
4. Press the OK button after each adjustment has been made to store the required values.
5. To exit the Service Mode, press the "N" button.
Alignment Function
Setting indication
Note: All setting values are approximate
Settings / Special features
EAROM copy TV/EXT ---
FLASH program copy EXT -> TV ---
Horizontal Position
H-Pos
-15
Optimum setting.
Vertical Position
V-Pos
10
Optimum setting.
Horizontal Amplitude
H-Amp
85
Optimum setting.
Vert. Amplitude
V-Amp
22
Optimum setting.
EW-amplitude
EW-Amp 1
- 20
Optimum setting.
Lower Corner
Lower Corner
5
Optimum setting.
Trapezium-comp
Trapez 1
-4
Optimum setting.
Upper Corner
Upper Corner
3
Optimum setting.
Vertical Linearity
V-Lin
24
Optimum setting.
Vertical Symmetry
V-Sym
-12
Optimum setting.
Angle
Angle
2
Optimum setting.
Bow
Bow
-2
Optimum setting.
DVCO
DVCO
-1
Receive a PAL Colour Bar Pattern. For
DVCO alignment press "Blue" button, wait
until the figure colour is changed from red
to black colour.
Highlight
Lowlight
High 0451 0401 0380
Low 0270 0277 0256
Optimum setting.
Sub-Brightness
Sub-Brightness
7
Optimum setting.
