Panasonic TX-32PX10D - Replacement Parts List

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type
number to your order.
REPLACEMENT PARTS LIST
Important Safety Notice
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
SPEAKER 1 EASG16S503F2
REMOTE CONTROL 2 EUR511212A
ANODE LEAD 3 KFT7CM446F1
TUNER 4 TADF4-301B
PANASONIC BADGE 5 TBM0E0101
POWER BUTTON 6 TBX0E80700
CRT FIXING SCREW 7 THT1062
DOOR LID 8 TKP0E11501
AV PANEL 9 TKP0E11801
G P.C.B. 10 TNP8EG005AT
H P.C.B. 11 TNP8EH008AC
AC CORD 12 TXASX01DBYG1
MISCELLANEOUS COMPONENTS
BATTERY . R6RC/2P
SET FOOT (REAR) . TBLG3020
PRESET LABEL . TBM0E0080
PRESET LABEL . TBM0E0081
LID SWITCH . TEK6935
POWER BUTTON SPRING. TES8E20
CRT SUPPORT BRACKET R. TKK0E9507
CRT SUPPORT BRACKET L. TKK0E9508
DOOR LID PANEL . TKP0E11601
LED COVER . TKP0E11701
ROTATION COIL . TLK8E05196
LED HOLDER . TMW8E050-2
PCB CLIP . TMW8E056-1
I.C.s
AUDIO OUTPUT IC251 LA4282
RGB OUTPUT IC351 TDA6111Q/N4
RGB OUTPUT IC361 TDA6111Q/N4
RGB OUTPUT IC371 TDA6111Q/N4
VERTICAL OUTPUT IC451 LA7876N
STANDBY CONTROL ICIC801 MIP0254SPSCF
POWER SUPPLY IC849 STRF6656LF57
ERROR AMPLIFIER IC899 SE130N
MICRO PROCESSOR IC1101 SDA6000-A23
SYSTEM RESET IC1103 PST9128NR
MOS LOGI IC IC1105 C0EAH0000105
64M SDRAM IC1106 C3ABPG000102
BUS LEVEL SHIFTERIC1107 TC7MBD3245FK
INVERTER IC1108 74LVC1GU04GW
VIDEO PROCESSOR IC1501 VSP9405VKB11
REGULATOR IC1502 BA18BC0FP
DEFLECTION PROCESSORIC1701 DDP3315CQAG3
EARTH CORRECTION IC1900 LA6515
AUDIO PROCESSOR IC2001 MSP3410GAB83
HEADPHONE AMPLIFIER IC2351 NJM4556AD
A/V MATRIX SWITCHIC3001 CXA2069Q-TL
RGB, FB MATRIX IC3301 TDA8601T/C1
REGULATOR IC3801 BA09ST-V5
REGULATOR IC3802 BA08T
3.3V REGULATOR IC3803 BA033T
REGULATOR IC3804 BA05T
REGULATOR IC3805 BA033ST-V5
REGULATOR IC3806 LD1117V25C
REGULATOR IC3807 BA05ST-V5
LED RECEIVER RC1001 RPM-6937
FUSES
FUSE HOLDERF801-L EYF52BC
FUSE HOLDERF801-R EYF52BC
FUSE F801 S5055AC
FS LINK R2810 TSF19252
DIODES
DIODE D101 MA3020TX
DIODE D102 MA3020TX
DIODED103 1SS355TE-17
DIODE D251 MA700ATA
DIODE D252 MA700ATA
DIODE D351 ERA15-04V3
DIODE D352 ERA15-04V3
DIODE D361 ERA15-04V3
DIODE D362 ERA15-04V3
DIODE D371 ERA15-04V3
DIODE D372 ERA15-04V3
DIODED376 1SS355TE-17
DIODED377 1SS355TE-17
DIODED378 1SS355TE-17
DIODE D387 MA2160LFS
DIODE D454 EU02V0
DIODE D456 MTZJT-776.8B
DIODE D457 1SS133T-77
DIODE D458 EU02V0
DIODE D501 1SS133T-77
DIODE D502 EU02V0
DIODE D503 1SS133T-77
DIODE D504 1SS133T-77
DIODE D505 MTZJT-7710D
DIODE D553 EU02V0
DIODE D554 EU02V0
DIODE D555 1SS133T-77
DIODE D556 UDZSTE-1722B
DIODE D557 ERB93-02E
DIODE D558 ERB93-02E
DIODE D559 1SS133T-77
13
