Panasonic TX-32PX10D - Page 25

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
I.C.s
8 MEG FLASH 29LV800BTCIC1102 EDF1/040/0F
32K EAROM 24C3210PI2.7IC1104 D00/2PD
COILS
COILL501 EXCELDR35C
COIL L582 ELC18B221L
COIL L584 ELH5L7727
CAPACITORS
CERAMICC551 ECKW3D271JBR 2kV 270pF
FILMC581 ECWF4624JBB 400V 620nF
FILMC582 ECWF4514JBB 400V 510nF
FILMC583 ECWH20512JVB 2kV 5.1nF
FILMC584 ECWH20562JVB 2KV 5.6nF
FILMC586 ECQF4153JZH 400V 15nF
FILMC587 ECQF4153JZH 400V 15nF
ELECTC916 ECA2CM100B 160V 10µF
TERMINALS AND LINKS
CRT SOCKET JK381 330550049
DIFFERENCES FOR MODEL TX--28PX10F
EXPLODED VIEW
A P.C.B. 13 TNP8EA007AU
BACK COVER 14 TKU0E0123
C.R.T. 15 W66EKT50X71
CABINET 16 TKY0E0127
CHASSIS FRAME 17 TMX0E404-1
D P.C.B. 18 TNP8ED005AH
DEGAUSS COIL 19 TLK8E05197
F.B.T. 21 KFT4AA432F
FOCUS LEAD ASSY 22 TXJ/FC0DEG1
L P.C.B. 23 TNP8EL020AL
MODEL LABEL 24 TBM0E0213
MISCELLANEOUS COMPONENTS
SET FOOT (FRONT) . TBLG3019
FRONT PANEL . TKE0E0301
CARTON . TPC0E43101
TOP CUSHION . TPD0E0034
BOTTOM CUSHION . TPD0E0035
INSTRUCTION BOOKS
GERMAN . TQB8E3958A-M
DUTCH . TQB8E3958B-M
FRENCH . TQB8E3958D-M
SPANISH . TQB8E3958E-M
SWEDISH . TQB8E3958F-M
NORWEGIAN . TQB8E3958G-M
FINNISH . TQB8E3958H-M
DANISH . TQB8E3958K-M
I.C.s
8 MEG FLASH 29LV800BTCIC1102 EDF1/040/0F
32K EAROM 24C3210PI2.7IC1104 D00/2PF
COILS
COILL501 EXCELDR35C
COIL L582 ELC18B221L
COIL L584 ELH5L7727
CAPACITORS
CERAMICC551 ECKW3D271JBR 2kV 270pF
FILMC581 ECWF4624JBB 400V 620nF
FILMC582 ECWF4514JBB 400V 510nF
FILMC583 ECWH20512JVB 2kV 5.1nF
FILMC584 ECWH20562JVB 2KV 5.6nF
FILMC586 ECQF4153JZH 400V 15nF
FILMC587 ECQF4153JZH 400V 15nF
ELECTC916 ECA2CM100B 160V 10µF
TERMINALS AND LINKS
CRT SOCKET JK381 330550049
DIFFERENCES FOR MODEL TX--32PX10D
EXPLODED VIEW
A P.C.B. 13 TNP8EA007AX
BACK COVER 14 TKU0E0119
C.R.T. 15 W76ELE50X71
CABINET 16 TKY0E0121
CHASSIS FRAME 17 TMX8E058-1
D P.C.B. 18 TNP8ED005AL
DEGAUSS COIL 19 TLK0E9011
DF P.C.B. 20 TNPA1806AT
F.B.T. 21 KFT5AW433F
FOCUS LEAD ASSY 22 TXJ/FC0CJEG
L P.C.B. 23 TNP8EL020AE
MODEL LABEL 24 TBM0E0086
MISCELLANEOUS COMPONENTS
SET FEET . TBL8E017
FRONT PANEL . TKE0E0102
CARTON . TPC0E43001
BOTTOM CUSHION . TPD0E0028
TOP CUSHION . TPD0E0029
SUB CUSHION . TPD0E1006
FBT SUPPORT BRACKET. TUX8E066
INSTRUCTION BOOKS
GERMAN . TQB8E3954A-M
ITALIAN . TQB8E3954C-M
FRENCH . TQB8E3954D-M
I.C.s
8 MEG FLASH 29LV800BTCIC1102 EDF1/030/0F
32 K EAROM 24C3210PI2IC1104 D00/1ND
DIODES
DIODE D521 AU02AV0
DIODE D522 AU02AV0
DIODE D523 MA165TA5VT
DIODE D524 MA165TA5VT
DIODE D525 RP1HLFA5
DIODE D526 RP1HLFA5
TRANSISTORS
TRANSISTOR Q521 2SK1006RF122
TRANSISTOR Q522 2SC3311ASTA
TRANSISTOR Q523 2SC3311ASTA
TRANSISTOR Q524 2SC5460LB
TRANSISTOR Q525 2SC3311ATA
TRANSFORMERS
TRANSFORMER T701 ETF18L101A
COILS
COIL L521 LHL13NB182JB
COILL582 ELC18B331E
COIL L584 ELH5L7719
RESISTORS
CARBONR520 ERDS2TJ153T 0.25W 5% 15K Ω
METALR521 ERG2FJS123D 2W 5% 12K Ω
CARBONR522 ERDS2TJ101T 0.25W 5% 100 Ω
CARBONR523 ERDS2TJ103T 0.25W 5% 10K Ω
CARBONR524 ERDS2TJ103T 0.25W 5% 10K Ω
CARBONR525 ERDS2TJ102T 0.25W 5% 1K Ω
SOLIDR526 ERC14GK184V 0.25W 10% 180K Ω
25
