DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CAPC1784 ECJ1VB1H103K 50V 10nF
TERMINALS AND LINKS
CRT SOCKET JK381 330770044
DIFFERENCES FOR MODEL TX--32PX10P
EXPLODED VIEW
A P.C.B. 13 TNP8EA007AX
BACK COVER 14 TKU0E0119
C.R.T. 15 W76ELE50X71
CABINET 16 TKY0E0121
CHASSIS FRAME 17 TMX8E058-1
D P.C.B. 18 TNP8ED005AL
DEGAUSS COIL 19 TLK0E9011
DF P.C.B. 20 TNPA1806AT
F.B.T. 21 KFT5AW433F
FOCUS LEAD ASSY 22 TXJ/FC0CJEG
L P.C.B. 23 TNP8EL020AE
MODEL LABEL 24 TBM0E0087
MISCELLANEOUS COMPONENTS
SET FEET . TBL8E017
FRONT PANEL . TKE0E0102
CARTON . TPC0E43001
BOTTOM CUSHION . TPD0E0028
TOP CUSHION . TPD0E0029
SUB CUSHION . TPD0E1006
FBT SUPPORT BRACKET. TUX8E066
INSTRUCTION BOOKS
BULGARIAN . TQB8E3960M-M
ROMANIAN . TQB8E3960N-M
POLISH . TQB8E3960P-M
HUNGARIAN . TQB8E3960Q-M
CZECH . TQB8E3960R-M
ENGLISH . TQB8E3960U-M
I.C.s
8 MEG FLASH 29LV800BTCIC1102 EDF1/030/0F
32 K EAROM 24C3210PI2IC1104 D00/1NP
DIODES
DIODE D521 AU02AV0
DIODE D522 AU02AV0
DIODE D523 MA165TA5VT
DIODE D524 MA165TA5VT
DIODE D525 RP1HLFA5
DIODE D526 RP1HLFA5
TRANSISTORS
TRANSISTOR Q521 2SK1006RF122
TRANSISTOR Q522 2SC3311ASTA
TRANSISTOR Q523 2SC3311ASTA
TRANSISTOR Q524 2SC5460LB
TRANSISTOR Q525 2SC3311ATA
TRANSFORMERS
TRANSFORMER T701 ETF18L101A
COILS
COIL L521 LHL13NB182JB
COILL582 ELC18B331E
COIL L584 ELH5L7719
RESISTORS
CARBONR520 ERDS2TJ153T 0.25W 5% 15K Ω
METALR521 ERG2FJS123D 2W 5% 12K Ω
CARBONR522 ERDS2TJ101T 0.25W 5% 100 Ω
CARBONR523 ERDS2TJ103T 0.25W 5% 10K Ω
CARBONR524 ERDS2TJ103T 0.25W 5% 10K Ω
CARBONR525 ERDS2TJ102T 0.25W 5% 1K Ω
SOLIDR526 ERC14GK184V 0.25W 10% 180K Ω
SOLIDR527 ERC14GK224V 0.25W 10% 220K Ω
CARBONR530 ERDS2TJ101T 0.25W 5% 100 Ω
SOLIDR531 ERC14GK334V 0.25W 10% 330K Ω
CARBONR532 ERDS2TJ473T 0.25W 5% 47K Ω
METALR533 ERG3FJS561D 3W 5% 560 Ω
CARBONR534 ERDS2TJ333T 0.25W 5% 33K Ω
METALR535 ERG1FJS332D 1W 5% 3K3 Ω
METALR536 ERG3FJS681D 3W 5% 680 Ω
SOLIDR537 ERC12GK104D 0.5W 10% 100K Ω
SOLIDR538 ERC14GK225V 0.25W 10% 2M2 Ω
CARBONR540 ERDS2TJ560T 0.25W 5% 56 Ω
S.M.CARBR1793 ERJ3GEYJ153V 0.1W 5% 15K Ω
CAPACITORS
CERAMICC521 ECKR3A182KBP 1KV 1.8nF
CERAMICC522 ECKW3A272KBP 1kV 2.7nF
CERAMICC523 ECKR3A151KBP 1kV 150pF
FILMC524 ECQM6223JZW 630V 22nF
FILMC525 ECQM4223JZW 400V 22nF
CERAMICC526 ECKW3D101KBP 2kV 100pF
ELECTC527 ECA1HM010B 50V 1µF
CERAMICC528 ECKW3D471KBP 2KV 470pF
ELECTC529 ECA1HM100B 50V 10µF
CERAMICC530 ECKR3A681KBP 1kV 680pF
CERAMICC531 ECKW3D102KBP 2kV 1nF
FILMC581 ECWF4684JBB 400V 680nF
FILMC582 ECWF4474JBB 400V 470nF
FILMC583 ECWH20562JVB 2KV 5.6nF
FILMC584 ECWH20622JVB 2KV 6.2nF
FILMC586 ECQF4103JZH 400V 10nF
FILMC587 ECQF4103JZH 400V 10nF
ELECTC916 ECA2CM220B 160V 22µF
S.M.CAPC1784 ECJ1VB1H103K 50V 10nF
TERMINALS AND LINKS
CRT SOCKET JK381 330770044
