Panasonic TX-36PG50D - Replacement Parts List

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type
number to your order.
REPLACEMENT PARTS LIST
Im
p
ortant Safet
y
Notice
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
SPEAKER (WOOFER) 1 EAB12149C2
SPEAKER (TWEETER) 2 EASG7DH08B2
TUNER 3 ENG29507G
TUNER 4 ENG29C01G
REMOTE CONTROL 5 EUR511224
POWER BUTTON 6 TBXA24302
CRT FIXING SCREW 7 THT1062
AV COVER 8 TKP8E1323-1
H P.C.B. 9 TNPA1724
DP P.C.B EXCHANGE UNIT 10 TNPA1727
K P.C.B. 11 TNPA1729
Z P.C.B. 12 TNPA1739
DF P.C.B. 13 TNPA1806
DG P.C.B EXCHANGE UNIT 14 TNPA1965AB
U P.C.B. 15 TNPA2042AL
DOOR LID 16 TTPA0128
POWER CORD 17 TXASX01CJJG
FOCUS LEAD ASSEMBLY 18 TXJF0C0EFG
BATTERY COVER (REMOTE) 19 UR51EC904A
F.B.T. 20 ZTFM77009A
MISCELLANEOUS COMPONENTS
RUBBER FOOT . TBL63413
AV LABEL . TBM8E2038
LEFT PRESET LABEL. TBMU101
RIGHT PRESET LABEL. TBMU102
DOOR CATCHER . TEKX008
CRT EARTH SPRING . TES2298
HANDLE . TKRA13110
LED HOLDER . TMWJ019-1
POWER BUTTON JOINT. TMX8E051
SERVICE PACK . TZS1EK002
BATTERY PACK . UM-3DJ-2P
I.C.s
REGULATOR D354 TL431CLPM
5V REGULATOR IC051 AN7805FLB
RGB OUTPUT IC351 TDA6111Q-N4
RGB OUTPUT IC352 TDA6111Q-N4
RGB OUTPUT IC353 TDA6111Q-N4
MULTIVIBRATOR IC459 TC74HC221AF
AUDIO AMPLIFIER IC501 NJM2903MTE1
POWER SUPPLY IC801 STRF6656LF53
POWER SUPPLY SWITCHINGIC841 MIP0254SPSCF
ERROR AMPLIFIER IC851 SE140N
MICRO PROCESSOR IC1101 SDA6000-A23
EEPROM * IC1102 E2F0/010/05
5V REGULATOR IC1105 S-80843ALY-Z
SDRAM IC1106 TVSA0395
CONVERTER IC1107 TC7MBD3245FK
5V REGULATOR IC1108 AN78L05TA
SYSTEM RESET IC1109 PST9119NR
RESET IC1110 PST9128NR
3.5V REGULATOR IC1251 SI-3033C
2.5V REGULATOR IC1252 PQ30RV21B
D/A CONVERTER IC1253 M62392FP70BC
RESET IC1254 PST9128NR
R.G.B. PROCESSOR IC1315 AN5394FB
M.S.P. IC2001 MSP3410DQAC5
AUDIO AMPLIFIER IC2301 TDA7490
H.P. AMPLIFIER IC2302 AN7108
QUAD AMPLIFIER IC2303 NJM2059MTE1
AUDIO AMPLIFIER IC2305 TDA7481
QUAD AMPLIFIER IC2306 NJM2059MTE1
QUAD AMPLIFIER IC2307 NJM2059MTE1
POWER SUPPLY IC2401 STR10006-N
2.5V REGULATOR IC2402 PQ30RV21B
AUDIO AMPLIFIER IC2403 TDA2030AV
AUDIO AMPLIFIER IC2404 TDA2030AV
AUDIO AMPLIFIER IC2405 TDA2030AV
AUDIO AMPLIFIER IC2406 TDA2030AV
BUFFER IC2407 TC7WU04FEL
REGULATOR IC2705 PQ1CG21H2RZ
REGULATOR IC2706 PQ1CG21H2RZ
8V REGULATOR IC2707 AN7808LB
POWER SUPPLY IC2708 SI-8090K
REGULATOR IC2709 PQ1CG21H2RZ
SWITCHING IC3001 CXA2069Q-TL
12V REGULATOR IC3002 TDA8601T/C1
VIDEO AMPLIFIER IC3003 CXA1211M-T4
12V REGULATOR IC3302 L78M12MRB
OPERATIONAL AMPLIFIER IC4801 AN6564NS-E1
GEOMAGNETIC CORRECTIONIC4802 PUB4301
LED RECEIVER RM1001 RPM6937-S
FUSES
FUSE HOLDER F801-2 EYF52BC
FUSE HOLDER F801-1 EYF52BC
FUSE F801 XBA2C50TH15
DIODES
DIODE D001 MA4020
DIODE D002 MA4020
DIODE D003 MA3150HTX
DIODE D004 MA3150HTX
DIODE D010 MA152KTX
DIODE D051 MA4020
DIODE D052 MA4020
DIODE D053 MA152KTX
DIODE D351 ERA15-04V3
