Panasonic TX-50DX802B - Page 38

Model No. : TX-50DX802B Parts List
Change Safety
Ref.
No.
Part
No. Part Name & Description Q'ty Remarks
PCB A-50DX802B CIRCUIT BOARD A 1 (RPL)PAVCCZ
PCB TXN/K1XPVE CIRCUIT BOARD K 1 (RPL)PAVCCZ
PCB TXN/P1ASWE CIRCUIT BOARD P 1 (RPL)PAVCCZ
A02A K1KY26BA0484 26P CONNECTOR 1 PAVCCZ
A10 K1KY12BA0483 12P CONNECTOR 1 PAVCCZ
A12 K1FY114B0021 14P CONNECTOR 1 PAVCCZ
A15 K1MY41BA0665 41P CONNECTOR 1 PAVCCZ
A16 K1MY51BA0665 51P CONNECTOR 1 PAVCCZ
C2000 F1G1H102A830 C 1000PF, , 50V 1 PAVCCZ
C2001 F1G1E103A144 C 0.01UF, , 25V 1 PAVCCZ
C2002 F1G1E103A144 C 0.01UF, , 25V 1 PAVCCZ
C2003 F1K1E106A167 C 10UF, , 25V 1 PAVCCZ
C2005 F1G1H102A830 C 1000PF, , 50V 1 PAVCCZ
C2006 F1G1C104A146 C 0.1UF, , 16V 1 PAVCCZ
C2008 F1G1H102A830 C 1000PF, , 50V 1 PAVCCZ
C2010 F1G1H102A830 C 1000PF, , 50V 1 PAVCCZ
C2011 F1G1H102A830 C 1000PF, , 50V 1 PAVCCZ
C2021 F1G1H221A834 C 220PF, -, 50V 1 PAVCCZ
C2022 F1G1H221A834 C 220PF, -, 50V 1 PAVCCZ
C2023 F1G1H221A834 C 220PF, -, 50V 1 PAVCCZ
C2024 F1G1H221A834 C 220PF, -, 50V 1 PAVCCZ
C2056 F1G1E103A144 C 0.01UF, , 25V 1 PAVCCZ
C2057 F1G1E103A144 C 0.01UF, , 25V 1 PAVCCZ
C2112 F1G1E103A144 C 0.01UF, , 25V 1 PAVCCZ
C2113 F1G1E103A144 C 0.01UF, , 25V 1 PAVCCZ
C2114 F1G1E103A144 C 0.01UF, , 25V 1 PAVCCZ
C2120 F1G1H102A830 C 1000PF, , 50V 1 PAVCCZ
C2253 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C2257 F1G1E103A144 C 0.01UF, , 25V 1 PAVCCZ
C2258 F1G1E103A144 C 0.01UF, , 25V 1 PAVCCZ
C2262 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C2801 F1H1H103B047 C 10NF, , 50V 1 PAVCCZ
C2804 F1H1C104A178 C 0.1UF, -, 16V 1 PAVCCZ
C2807 F1J1A106A043 C 10UF, , 10V 1 PAVCCZ
C2808 F1H1C104A178 C 0.1UF, -, 16V 1 PAVCCZ
C2851 F1J1H104A902 C 100NF, , 50V 1 PAVCCZ
C2852 F1J1H104A902 C 100NF, , 50V 1 PAVCCZ
C3109 F1G1H100A963 C 10PF, D, 50V 1 PAVCCZ
C3110 F1G1H100A963 C 10PF, D, 50V 1 PAVCCZ
C3111 F1G1H100A963 C 10PF, D, 50V 1 PAVCCZ
C3112 F1G1H152A946 C 1500PF, K, 50V 1 PAVCCZ
C3113 F1G1C103A173 C 0.01UF, K, 16V 1 PAVCCZ
C3114 F1G1C103A173 C 0.01UF, K, 16V 1 PAVCCZ
C3115 F1G1C103A173 C 0.01UF, K, 16V 1 PAVCCZ
C3116 F1G1C103A173 C 0.01UF, K, 16V 1 PAVCCZ
C3117 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C3124 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C3125 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C3127 F1G1A473A079 C 47NF, , 10V 1 PAVCCZ
C3128 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C3129 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C3134 F1G1C104A146 C 0.1UF, , 16V 1 PAVCCZ
C3135 F1G1C104A146 C 0.1UF, , 16V 1 PAVCCZ
C3163 F1G1H101A948 C 100PF, J, 50V 1 PAVCCZ
C3164 F1G1H101A948 C 100PF, J, 50V 1 PAVCCZ
C3166 F1G1H470A948 C 47PF, J, 50V 1 PAVCCZ
C3167 F1G1H470A948 C 47PF, J, 50V 1 PAVCCZ
C3168 F1G1H470A948 C 47PF, J, 50V 1 PAVCCZ
C3200 F1G1C104A146 C 0.1UF, , 16V 1 PAVCCZ
C3201 F1H1A225A051 C 2200NF, , 10V 1 PAVCCZ
38
