Panasonic TX-L42E30E - Self Check

Self Check
Self-check is used to automatically check the bus lines and hexadecimal code of the TV set. To enter Self-Check mode, keep
pressing the down (-/v) button on the TV set and press the STATUS button on the remote control. To exit Self Check,
switch off the TV set at the power button.
* Displayed for E, LF model only
Display Ref. No. Description P.C.B.
TUN TU4801 TUNER A-Board
STBY IC8000 Peaks-LDA3 A-Board
MEM1 IC8901 STM EEPROM A-Board
MEM2 IC8902 EEPROM PEAKS LDA3 A-Board
AVSW IC3001 AUDIO VIDEO SWITCH A-Board
LAN IC8601 ETHERNET IF A-Board
ZWEI TC-unit TC-unit on panel TC-unit
ID* IC8902 (CI+) , DTCP-IP, One-to-One A-Board
ID2 IC8902 WIDEVINE A-Board
HDMI SW IC4700 HDMI SWITCH A-Board
If the CCU
p
orts have been checked and found to be incorrect or not located then " - - " will a
pp
ear in
p
lace of "O.K.".
TX-L42E30E
42FHD Panasonic 2011LCD
Self Check Com
p
lete
TUN O.K.
STBY O.K.
MEM1 O.K.
MEM2 O.K..
AVSW O.K.
LAN O.K.
ZWEI O.K.
ID O.K.
ID2 O.K.
HDMI-SW O.K.
PEAKS-SOFT 1.110
PEAKS-EEP 01.00.0003
LSI-PACKAGE 0.914
LSI-RELEASE 1.02
STBY-SOFT 1.00.00
STBY-EEP 1.00.0500
STBY-ROMCORR 0.00.00
ZWEI-SOFT 15000100
SUM 9048
MODEL ID 08
03167100
00000020
TX-LF42E30
42FHD Panasonic 2011LCD
Self Check Com
p
lete
TUN O.K.
STBY O.K.
MEM1 O.K.
MEM2 O.K..
AVSW O.K.
LAN O.K.
ZWEI O.K.
ID O.K.
ID2 O.K.
HDMI-SW O.K.
PEAKS-SOFT 1.110
PEAKS-EEP 01.00.0003
LSI-PACKAGE 0.914
LSI-RELEASE 1.02
STBY-SOFT 1.00.00
STBY-EEP 1.00.0500
STBY-ROMCORR 0.00.00
ZWEI-SOFT 15000100
SUM 9048
MODEL ID 08
03167100
00000020
TX-LR42E30
42FHD Panasonic 2011LCD
Self Check Com
p
lete
TUN O.K.
STBY O.K.
MEM1 O.K.
MEM2 O.K..
AVSW O.K.
LAN O.K.
ZWEI O.K.
ID2 O.K.
HDMI-SW O.K.
PEAKS-SOFT 1.110
PEAKS-EEP 01.00.0022
LSI-PACKAGE 0.914
LSI-RELEASE 1.02
STBY-SOFT 1.00.00
STBY-EEP 1.00.0500
STBY-ROMCORR 0.00.00
ZWEI-SOFT 15000100
SUM 8F7C
MODEL ID 08
031B7100
00000020
