Panasonic TX-L42E30E - Replacement Parts List

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type number to your order.
Replacement Parts List
Important Safety Notice
The marking (RTL) indicates that the Retention Time is Limited for this item. After the
discontinuation of this assembly in production, the item will continue to be available for
a specific period of time. The retention period of availability is dependent on the type of
assembly, and in accordance with the laws governing part and product retention. After
the end of this period, the assembly will no longer be available.
RTL (Retention Time Limited)
Note:
X
The marking (X) indicates that board should be exchanged for service.
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
BATTERY COVER OF RC 1 BAT-C-0490
TUNER DVB-T/T2/C 2 ENGS7302D5F
AC CORD 3 K2CQ2YY00083
SPEAKER UNIT 4 L0AA16C00003
REMOTE CONTROL 5 N2QAYB000490
PACKED STAND ASSY 6 TBL5ZX0149
STAND MOUNT ASSY 7 TBL5ZX0166
COVER LABEL 8 TBM4GU113
POWER BUTTON 9 TBX0E50200
SIDE AV BRACKET 10 TKP0E47801
BACK COVER 11 TKU0E7801
SP BRACKET L 12 TKX4GA04901
SP BRACKET R 13 TKX4GA05001
LCD SUPPORT METAL 14 TKZ4GA5001
METAL BRACKET BOTTOM 15 TKZ4GX5094
BARRIER LCD ASSY 16 TMK0EX047
BARRIER BC ASSY 17 TMK0EX048
LD P.C.B. 18 TNPA5376AA
KA P.C.B. 19 TNPA5378AB
CI SLOT COVER SHEET 20 TQF4GX013
CONTROL PANEL ASSY 21 TXAKP01PQUE
BOTTOM COVER ASSY 22 TXFKX01PRUE
CABINET ASSY 23 TXFKY5Z0051
P P.C.B. 24 TZRNP01PLUE
LCD PANEL 25 VVX42F115G00
MISCELLANEOUS COMPONENTS
BATTERY . R6DB/2P
REAR AV LABEL . TBM0E2493
SIDE AV LABEL . TBM0E2497
LOGO SHEET . TBM0E3009
SCREW . THE4GJ001J
SCREW . THEJ036J
SCREW . THEJ0389
M6_CAP . TKKL5521
LED PANEL . TKP4GA06901
PROTECTION SHEET . TPE0E4043
POLYBAG_PEDESTAL . TPE0E9004
BAG . TPE0E9008
LABEL . TQF0EM3534
SCREW . XSS5+15FNK
SCREW . XTB4+15JFJ
SCREW . XTB4+15JFJK
SCREW . XTV3+10GFJK
SCREW . XTV3+8JFJ
SCREW . XTW3+10TFJ
SCREW .XYN3+C8FJ
SCREW . XYN4+F30FJK
SCREW . XYN5+F14FN
BOTTOM CUSHION CENTREBOTCUS1 TPD0E2174
BOTTOM CUSHION BOTCUS2 TPD0E2173
CLAMPER CA01 TMME397
CLAMPER CA02 TMME397
CLAMPER CA03 TMME397
CLAMPER CA04 TMME397
CARTON CARTON TPC0EA06801
CLAMPER CK304 TMME268
CLAMPER CK305 TMME268
CLAMPER CK307 TMME268
CLAMPER CK308 TMME268
CLAMPER CK309 TMME268
SPACER CP01 TMME398
SPACER CP02 TMME398
SPACER CP03 TMME398
SPACER CP04 TMME398
SPACER CP05 TMME398
SPACER CP06 TMME398
SPACER CP07 TMME398
SP. SPONGE FK201 TMK0EG030
SP. SPONGE FK202 TMK0EG030
GASKET FK310 TEWB412
TOP CUSHION CENTERTOPCUS1 TPD0E1168
TOP CUSHION TOPCUS2 TPD0E1167
I.C.s
AUDIO VIDEO SWITCHIC3001 C1AB00003384
HDMI SWITCH IC4700 C1AB00003469
AUDIO AMPLIFIER IC4900 C1AB00003457
ANALOG ASIC IC5000 AN34043A-VF
REGULATOR IC5205 C0DBGYY00281
REGULATOR IC5300 C0DBAYY00462
REGULATOR IC5400 C0DBAYY00915
REGULATOR IC5420 C0DBAYY00915
REGULATOR IC5440 C0DBAYY01058
SWITCH IC IC5602 C0DBZYY00368
SWITCH IC IC5603 C0DBZYY00368
USB POWER SWITCH IC5605 C0DBZYY00450
POWER FACTOR CONTROLIC7201 C0DBBYY00033
PWM CONTROLLER IC7301 C5HAZYY00014
REGULATOR IC7502 C0DBZMC00006
DC/DC CONVERTER IC7601 C0DBAYY00922
PEAKS_LDA3 IC8000 MN2WS0200LE
