DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
DC/DC CONVERTER IC8100 C0DBAYY00715
DDR SDRAMIC8200 C3ABUY000009
DDR SDRAM IC8201 C3ABTY000026
BUFFER IC8403 C0JBAZ003032
POWER SWITCH IC IC8404 C0DBZYY00382
PHYSICAL LAYER TRANSCEIC8601 C1CB00003491
REGULATOR IC8702 C0CBCAG00039
REGULATOR IC8703 C0DBAFF00019
REGULATOR IC8706 C0DBAGF00030
NAND FLASH MEMORY IC8900 TVRS076AA
LED DRIVER WITH DC/DCIC9500 C0ZBZ0001816
LED DRIVER WITH DC/DCIC9600 C0ZBZ0001816
PHOTO COUPLER PC7301 B3PAA0000363
PHOTO COUPLER PC7302 B3PAA0000363
PHOTO COUPLER PC7303 B3PAA0000363
RC RECEIVER RM2800 PNJ4815M01TV
PHOTO IC DIODE SN2800 B3JB00000078
FUSES
FUSE HOLDER F7101-2 K3GE1ZA00010
FUSE HOLDER F7101-1 K3GE1ZA00010
FUSE F7101 K5D502BNA005
FUSE PA5300 K5H5022A0031
FUSE PA5440 K5H5022A0031
FUSE PA7503 K5H502YA0063
FUSE PA7504 K5H502Y00004
FUSE PA7601 K5H502Y00004
DIODES
DIODE D1101 B0JCCD000020
VARISTOR D2016 EZJZ0V120JA
LED DIODE D2800A B3AGB0000065
DIODE D3130 DA2J10100L
DIODE D4702 DA2J10100L
DIODE D4704 B0JCCD000020
DIODE D4719 DA2J10100L
DIODE D4721 B0JCCD000020
DIODE D4735 DA2J10100L
DIODE D4737 B0JCCD000020
DIODE D4770 DA2J10100L
DIODE D4772 B0JCCD000020
DIODE D4785 B0JCCD000020
DIODE D5172 DZ2J220M0L
DIODE D5173 DA2J10100L
ZENER DIODE D5178 DZ2J068M0L
DIODE D5179 DA2J10100L
ZENER DIODE D5180 DZ2J033M0L
ZENER DIODE D5183 DZ2J068M0L
DIODE D5184 DA2J10100L
ZENER DIODE D5187 DZ2J047M0L
DIODE D5188 DA2J10100L
DIODE D5207 B0JCCD000020
DIODE D5301 B0JCMD000066
DIODE D5440 B0JCPE000038
VARISTOR D7101 ERZV10V621C2
DIODE D7102 B0FBAT000018
DIODE D7202 B0ADCJ000100
DIODE D7203 B0JAME000091
DIODE D7204 B0JAME000091
DIODE D7205 B0HASR000018
ZENER DIODE D7207 DZ2J068M0L
DIODE D7208 DA2J10100L
DIODE D7209 B0BC02500002
DIODE D7302 B0HAGQ000001
DIODE D7303 B0HAGQ000001
ZENER DIODE D7313 DZ2J068M0L
DIODE D7325 B0BC02500002
DIODE D7326 DA2J10100L
DIODE D7327 DA2J10100L
DIODE D7328 DA2J10100L
DIODE D7329 B0ACDJ000014
DIODE D7330 B0ACDJ000014
ZENER DIODE D7331 B0BC4R000002
DIODE D7332 B0HAGQ000001
DIODE D7333 B0JAME000126
DIODE D7334 B0ADCJ000100
DIODE D7335 DZ2J180M0L
DIODE D7336 B0BC03300012
DIODE D7337 B0BC02500002
DIODE D7338 B0BC02500002
DIODE D7339 B0BC02500002
DIODE D7341 B0BC02500002
DIODE D7342 DA2J10100L
DIODE D7343 DA2J10100L
DIODE D7501 B0JBSL000047
DIODE D7502 B0JBSL000047
DIODE D7507 B0ADCJ000100
DIODE D7508 DA2J10100L
DIODE D7600 B0JCPE000038
DIODE D8716 B0ECKM000048
DIODE D9500 B0FCAM000001
DIODE D9509 DZ2J120M0L
ZENER DIODE D9510 B0BC6R600005
DIODE D9520 DB2J41100L
DIODE D9521 B0ECKM000048
DIODE D9522 B0ECKM000048
DIODE D9600 B0FCAM000001
ZENER DIODE D9610 B0BC6R600005
DIODE D9620 DB2J41100L
DIODE D9621 B0ECKM000048
DIODE D9622 B0ECKM000048
TRANSISTORS
TRANSISTOR Q0900 B1ADCF000194
TRANSISTOR Q2800 B1ABCE000015
TRANSISTOR Q2801 B1ABCE000015
TRANSISTOR Q2802 B1ABCE000015
TRANSISTOR Q3102 B1ABCF000231
TRANSISTOR Q3103 B1ABCF000231
TRANSISTOR Q3104 B1ABCF000231
TRANSISTOR Q3105 B1ABCF000231
TRANSISTOR Q4512 B1HFCFA00026
TRANSISTOR Q4513 B1ADCE000022
TRANSISTOR Q4700 B1ABCF000231
TRANSISTOR Q4702 B1ABCF000231
TRANSISTOR Q4704 B1ABCF000231
TRANSISTOR Q4709 B1ABCF000231
TRANSISTOR Q4971 B1AAFB000002
TRANSISTOR Q4972 B1AAFB000002
TRANSISTOR Q4974 DSC2001S0L
TRANSISTOR Q7201 B1CERR000057
TRANSISTOR Q7202 B1HFCFA00020
TRANSISTOR Q7301 B1ADCE000022
TRANSISTOR Q7308 B1ADGJ000008
TRANSISTOR Q7309 B1ABGF000019
TRANSISTOR Q7310 B1ABCF000231
TRANSISTOR Q7311 B1ABCF000231
TRANSISTOR Q7312 B1ADCE000022
TRANSISTOR Q7313 B1CBGD000001
TRANSISTOR Q7314 B1ABCF000231
TRANSISTOR Q7501 B1ABCF000231
TRANSISTOR Q7502 B1ABCF000231
TRANSISTOR Q7503 B1CHRE000005
TRANSISTOR Q7504 B1CHRE000005
TRANSISTOR Q7506 B1CHRE000005
TRANSISTOR Q7507 B1ABCF000231
TRANSISTOR Q8100 B1CFRD000077
