Panasonic TX-P50G30E - Specifications; Technical Specifications Overview

Specifications
102
Specifications
TX-P42G30E TX-P46G30E TX-P50G30E
Power Source AC 220-240 V, 50 / 60 Hz
Rated Power Consumption 275 W 285 W 320 W
On mode Average Power
Consumption
( based on IEC 62087 Ed.2
measurement method)
122 W 150 W 175 W
Standby Power Consumption
0.40 W
16.00 W (With monitor out recording)
Dimensions (W × H × D)
1,020 mm × 675 mm ×
320 mm (With Pedestal)
1,118 mm × 730 mm ×
335 mm (With Pedestal)
1,204 mm × 779 mm ×
335 mm (With Pedestal)
1,020 mm × 640 mm ×
70 mm (TV only)
1,118 mm × 695 mm ×
70 mm (TV only)
1,204 mm × 744 mm ×
70 mm (TV only)
Mass
24.0 k
Net (With Pedestal) 27.5 k Net (With Pedestal) 30.0 k Net (With Pedestal)
20.5 k Net (TV only) 23.5 k Net (TV only) 26.0 k Net (TV only)
Display panel
Aspect Ratio 16:9
Visible screen size
106 cm (diagonal)
921 mm (W) × 518 mm (H)
117 cm (diagonal)
1,019 mm (W) × 573mm (H)
127 cm (diagonal)
1,105 mm (W) × 662 mm (H)
Number of pixels 2,073,600 (1,920 (W) × 1,080(H)) [5,760 × 1,080 dots]
Sound
Speaker (140 mm × 35 mm) × 2, 6 Ω
Audio Output 20 W (10 W + 10 W)
Headphones M3 (3.5 mm) stereo mini Jack × 1
Receiving Systems /
Band name
C heck the latest information
on the available services at the
following website.
(English only)
http://panasonic.jp/support/
global/cs/tv/
PAL B, G, H, I,
SECAM B, G,
SECAM L, L’
VHF E2 - E12
VHF A - H (ITALY)
CATV (S01 - S05)
CATV S11 - S20 (U1 - U10)
VHF H1 - H2 (ITALY)
UHF E21 - E69
CATV S1 - S10 (M1 - M10)
CATV S21 - S41 (Hyperband)
PAL D, K,
SECAM D, K
VHF R1 - R2 VHF R3 - R5
VHF R6 - R12 UHF E21 - E69
PAL 525/60 Playback of NTSC tape from some PAL Video recorders (VCR)
M.NTSC Playback from M.NTSC Video recorders (VCR)
NTSC (AV input only) Playback from NTSC Video re
corders (VCR)
DVB-T D igital terrestrial services (MPEG2 and MPEG4-AVC(H.264))
DVB-C D igital cable services (MPEG2 and MPEG4-AVC(H.264))
Aerial input VHF / UHF
Operating Conditions
Temperature : 0 °C - 35 °C
Humidity : 20 % - 80 % RH (non-condensing)
Connection Terminals
AV1 (SCART) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in, Q-Link)
AV2 input
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 Ω)
AUDIO L - R RCA PIN Type × 2 0.5 V[rms]
COMPONENT input
Y 1.0 V[p-p] (including synchronization)
P
B, PR ±0.35 V[p-p]
HDMI 1 / 2 / 3 / 4 input
TYPE A Connectors
HDMI1 / 3 / 4 : HDMI (Version 1.4 with Content Type), Deep Colour, x.v.Colour™
HDMI2 : HDMI (Version 1.4 with Content Type, Audio Return Channel), Deep Colour,
x.v.Colour™
•
T his TV supports “HDAVI Control 5” function.
