Accessories / Options
Quick Start Guide
8
1
Assembling the pedestal
U se the assembly screws
A
to fasten the pole
D
to
the base
E
securely.
•
M ake sure that the screws are securely tight ened.
•
F orcing the assembly screws the wrong way will
strip the threads.
2
Securing the TV
U se the assembly screws
B
to fasten securely.
•
T ighten the four assembly screws loosely at first, then
tighten them firmly to fix securely.
•
C arry out the work on a horizontal and level surface.
B
E
H ole for pedestal
installation
(View from the bottom)
Arrow mark
A
E
D
Front
A ttach the cover
F
with assembly screw
C
F
C
Removing the pedestal from the TV
B e sure to remove the pedestal in the following way when using the wall-hanging bracket or repacking the TV.
1 Remove the assembly screws
B
from the TV.
2 Pull out the pedestal from the TV.
3 Remove the assembly screw
C
from the cover.
4 Pull out the cover.
5 Remove the assembly screws
A
from the pole.
Adjusting the panel to your desired angle
•
D o not place any objects within the full rotation range.
(View from the top)
: 15°
(TX-P42G30E)
: 10°
(TX-P46G30E, TX-P50G30E)
