Before using
Parts identification and handling
11
LSQT1048
26 Reset button [RESET] (l 109)
27 LCD monitor (l 13)
28 Mode select switch [AUTO/MANUAL/FOCUS]
(l 56)
29 Speaker
30 Disc eject lever [DISC EJECT] (l 24)
31 Disc access lamp [ACCESS/PC] (l 24)
32 Disc compartment (l 24)
33 Grip belt (l below)
Adjust the belt length so it fits your hand.
Adjust the belt length and the pad position.
1 Flip the belt.
2 Adjust the length.
3 Fix the belt.
Due to limitations in LCD production
technology, there may be some tiny bright or
dark spots on the LCD monitor screen.
However, this is not a malfunction and does
not affect the recorded picture.
26
2
8
27
2
9
30 31 32 33
Using grip belt
2
1
3
