Specifications
・
Licence
Glossary
・
Maintenance
・
Index
FAQs, etc.
71
Even if no special notation has been made of company or product trademarks, these trademarks have been fully
respected.
DVB and the DVB logos are trademarks of the DVB Project.
VGA is a trademark of International Business Machines Corporation.
Macintosh is a registered trademark of Apple Inc., USA.
S-VGA is a registered trademark of the Video Electronics Standard Association.
SDHC Logo is a trademark.
HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
HDAVI Control™ is a trademark of Panasonic Corporation.
GUIDE Plus+ is (1) a registered trademark or trademark of, (2) manufactured under license from and (3) subject
of various international patents and patent applications owned by, or licensed to, Gemstar-TV Guide International,
Inc. and/or its related affiliates.
Licence
Specifications
Power Source AC 220-240 V, 50 Hz
Power Consumption 36 W
Power Consumption in
Standby mode
0.4 W (Without monitor out recording)
13 W (With monitor out recording)
Display panel
Aspect Ratio 16:9
Visible screen size
47 cm (diagonal)
409 mm (W) × 230 mm (H)
Number of pixels 1,049,088 (1,366 (W) × 768 (H))
Sound
Speaker 72 mm × 31 mm × 2 pcs, 8
:
Audio Output 6 W (3 W + 3 W), 10% THD
Headphones M3 (3.5 mm) stereo mini Jack × 1
PC signals
VGA, SVGA, WVGA, XGA
SXGA, WXGA ······ (compressed)
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
Receiving Systems /
Band name
PAL I : UHF E21-68
PAL 525/60
: Playback of NTSC tape from some PAL Video recorders (VCR) or NTSC disc
playback from DVD player and recorder.
DVB-T : Digital terrestrial services via UHF aerial input.
M.NTSC : Playback from M.NTSC Video recorders (VCR).
NTSC (AV input only) : Playback from NTSC Video recorders (VCR).
Aerial - Rear UHF
Operating Conditions
Temperature : 0 °C - 35 °C
Humidity : 20 % - 80 % RH (non-condensing)
Connection Terminals
AV1 (Scart terminal) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in, Q-Link)
AV2 (Scart terminal) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in, S-Video in, Q-Link)
COMPONENT
VIDEO
Y 1.0 V[p-p] (including synchronization)
P
B, PR ±0.35 V[p-p]
AUDIO L - R
RCA PIN Type × 2 0.5 V[rms]
Others
HDMI
TYPE A Connector
This TV supports “HDAVI Control 4” function.
PC
HIGH-DENSITY D-SUB 15PIN R,G,B/0.7 V[p-p] (75
:
)
HD, VD/TTL Level 2.0 - 5.0 V[p-p] (high impedance)
Card slot SD Card slot × 1
Output
AUDIO L - R
RCA PIN Type × 2 0.5 V[rms] (high impedance)
Dimensions ( W × H × D )
472 mm × 361 mm × 174 mm (With Pedestal)
472 mm × 323 mm × 67 mm (TV only)
Mass
5.5 kg Net (With Pedestal)
5.0 kg Net (TV only)
Note
Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.
This equipment complies with the EMC standards listed below.
EN55013, EN61000-3-2, EN61000-3-3, EN55020, EN55022, EN55024.
