Specifications
TV 42” class 47” class
Model No. TH-L42ET5H TH-L47ET5H
Power Source AC 220 V, 50 / 60 Hz
Power
Consumption
Power Rating 110 W 134 W
Standby condition 0.2 W 0.2 W
Display
panel
Panel system IPS LED backlight Liquid Crystal Display
Visible screen size
(diagonal)
107 cm / 42 inches 119 cm / 47 inches
Number of pixels 2,073,600 (1,920 (W) × 1,080 (H))
Dimensions (W × H × D)
997 mm × 650 mm × 247 mm
(With Pedestal)
1,107 mm × 712 mm × 268 mm
(With Pedestal)
997 mm × 604 mm × 52 mm (TV only) 1,107 mm × 666 mm × 52 mm (TV only)
Mass
17.0
Net (With Pedestal) 20.5 Net (With Pedestal)
14.0
Net (TV only) 17.0 Net (TV only)
Sound
Speaker (75 mm × 22 mm) × 2, 8 Ω
Audio output 20 W (10 W + 10 W)
Headphones M3 (3.5 mm) stereo mini Jack × 1
Receiving systems /
Band name
17 Systems Function
1 PAL B, G, H
Reception
of broadcast
transmissions and
Playback from
Video Cassette
Tape Recorders
2 PAL I
3 PAL D, K
4 SECAM B, G
5 SECAM D, K
6 SECAM K1
7
NTSC M
(NTSC 3.58/4.5
MHz)
17 Systems Function
8 NTSC 4.43/5.5 MHz
Playback from
Special VCR’s or
DVD
9 NTSC 4.43/6.0 MHz
10 NTSC 4.43/6.5 MHz
11 NTSC 3.58/5.5 MHz
12 NTSC 3.58/6.0 MHz
13 NTSC 3.58/6.5 MHz
14 SECAM I
15 PAL 60 Hz/5.5 MHz
Playback from
Special Disc
Players and Special
VCR’s or DVD
16 PAL 60 Hz/6.0 MHz
17 PAL 60 Hz/6.5 MHz
GB20600-2006 Mode-C=3780 8 MHz UHF (Hong Kong) free-to-air TV Broadcast
reception
Receiving channels
(Analogue TV)
VHF BAND
2-12 (PAL/SECAM B, K1)
0-12 (PAL B AUST.)
1-9 (PAL B N.Z.)
1-12 (PAL/SECAM D)
1-12 (NTSC M Japan)
2-13 (NTSC M USA)
UHF BAND
21-69 (PAL G, H, I/SECAM G, K, K1)
28-69 (PAL B AUST.)
13-57 (PAL D, K)
13-62 (NTSC M Japan)
14-69 (NTSC M USA)
CATV
S1-S20 (OSCAR)
1-125 (USA CATV)
C13-C49 (JAPAN)
S21-S41 (HYPER)
Z1-Z37 (CHINA)
5A, 9A (AUST.)
Aerial - Rear VHF / UHF
Operating conditions
Temperature: 0 °C - 40 °C
Humidity: 20 % - 80 % RH (non-condensing)
