Outer/Inner View
ON
OFF
ON
OFF
● Power Switches
● Interface Ports
● Parallel Cable is used for Local Printer connection.
Telephone Cable is used for connecting the optional Fax
Communication Board (Order Number: DA-FG600) to the
telephone line.
Control Panel
Sheet Bypass
Front Cover
Right Cover
Paper Tray 1
Right Lower Cover
Paper Tray 2
Paper Tray 3
(Optional System
Console)
Paper Tray 4
(Optional System
Console)
Exit Cover
Left Cover
(Optional System Console)
ADF
(Automatic Document Feeder)
Toner
Bottle
Manual Pocket
Store the Operating
Instructions in the
Manual Pocket for
future reference.
Paper Transport Knob (Green)
Transport Release Lever (Green)
Fuser Knob
(Green)
Power Switch
Main Power Switch
Telephone
Line Cable
External
Telephone
Cable
LAN
Cable
Parallel
Cable
