1.6 Curvature of Torch Cable
• Appropriate torch cable length is designed for each
robot type. Use a right welding torch.
• Sharply bent torch cable makes wire feeding troubles.
Watch curvature of the torch cable at robot teaching
operation.
1.7 Installing Torch Body to Connector
Make sure to hold the torch body to insert it into the con-
nector. Holding the air blow base cover to insert the torch
body into the connector can damage the air blow base
cover.
Connector
Air blow base cover
Torch body
