USER MANUAL PANDORA ELITE V2
System set
1. Remote control 1
2. Radio tag 2
3. Leather case for a radio tag 1
4. Owner’s personal card 1
5. External VALET button 1
6. Beeper 1
7. Base unit 1
8. RF module RF-470 1
9. External GSM antenna 1
10. Relay module RMD-5M 1
11. External temperature sensors 1
12. Wires and fastening kit 1
13. Piezo siren PS-332BT 1
14. User manual 1
15. Wiring diagram 1
16. Packaging 1
! the mANufActuReR ReseRves the RIGht to chANGe the system set ANd coNstRuctIoN of the pRoduct to
ImpRove Its techNoloGIcAl ANd opeRAtIoNAl pARAmeteRs WIthout A NotIfIcAtIoN.
Read before using
Carefully read this manual before starting installation and using the security-service system. Pay
attention to text marked with
!
!
the secuRIty ANd telemetRIc system Is A complex techNIcAl pRoduct. system INstAllAtIoN ANd coNfIGuRAtIoN must be
cARRIed out oNly by A skIlled pRofessIoNAl.
! feAtuRes ANd system modes, coNtRol of the vehIcles zoNes depeNds oN the type of coNNectIoN ANd system settINGs,
oRIGINAl vehIcle opeRAtIoN loGIc ANd tRIm.
! the system set INcludes the “oWNeR’s peRsoNAl cARd”. thIs cARd coNtAINs INfoRmAtIoN uNdeR A pRotectIve lAyeR
thAt Is INteNded oNly foR the oWNeR of the system. mAke suRe thAt the pRotectIve lAyeR oN the oWNeR’s plAstIc cARd Is
INtAct AfteR the INstAllAtIoN of the system. ReAd the “oWNeR’s peRsoNAl cARd” sectIoN of thIs mANuAl befoRe eRAsING
the pRotectIve lAyeR.
! WheN system INstAllAtIoN Is fINIshed:
• check the system opeRAtIoN ANd fuNctIoNs WIth A specIAlIst.
• We RecommeNd thAt you mARk eAch WoRkING fuNctIoN WIth A sIGN IN the “coNtRol the system” sectIoN
• check thAt the “INstAllAtIoN ceRtIfIcAte” ANd “WARRANty cARd” ARe fIlled out. these documeNts mAy be RequIRed foR
coNtActING the customeR suppoRt.
• Ask AN INstAlleR to mARk the lAyout of the system compoNeNts oN the dIAGRAm. thIs INfoRmAtIoN mAy be RequIRed foR
dIAGNostIc/coNfIGuRING oR emeRGeNcy deActIvAtIoN of the system.
We RecommeNd thAt you chANGe the defAult vAlue of the pIN-codes of the system. you cAN WRIte doWN the chANGed
pIN-codes IN the “pIN-codes of the system” sectIoN.
