Lasershow Playe
r mode
l FB4 User Ma
nual
Color Outpu
ts
Color
Output
P
in
Signal Name
Voltage l
evel
1
Colo
r 1 (Red)
0 to +5V
2
Color 2 (Green)
0 to +5V
3
Color 3 (Blue)
0 to +5V
4
Color 4 (Deep Bl
ue)
0 to +5V
5
Color 5 (Yello
w)
0 to +5V
6
Color 6 (Cyan)
0 to +5V
7
Shutter
0 to +5V
8
GND
7
9
Table of Contents
Getting Started
3
Connecting to a Projector
4
Initial Operation
4
Software Setup
5
Power Input Connector
6
Status Indicator Lights
14
Power Connections
17
Signal Connections
22
