Panorama plus - Operator Panel and Indicators

Operator Panel and Indicators 4-1
4. Operator Panel and Indicators
The PANORAMA Monochrome Scanner Operator Panel (shown
overleaf) contains two keys and four indicators. The two operating
keys are positioned at the bottom: The Paper Reverse key (C), and
the Paper Feed/Forward key (A) with a Ready indicator (B) attached.
There are three indicators at the top: Power on (D), Wait (E), and
Diagnostic (F). The function of the keys and indicators are as follows:
4.1 Paper Feed/Forward Key & Ready indicator
• Insert the drawing face down into the scanner’s Insertion Slot, the
green Ready indicator (B) turns ON when the drawing is correctly
positioned.
• Now press the Feed Forward key (A), and the drawing moves into
the start-of-scan position (if auto-load is selected in WIDEimage
loading will take place automatically).
• The Ready indicator stays ON, signifying that the scanner is ready
to be controled from the computer.
• During scanning the Ready indicator will blink.
• At end of scanning the Ready indicator will stop blinking and again
turn ON signifying that scanning can be repeated from the
computer, or else terminated by pressing the Paper Feed/Forward
key to eject the drawing from the scanner.
• Pressing the Paper Feed/Forward key during scanning, stops the
scanning process and feeds the original as long as the key is
pressed.
4.2 Paper Reverse Key
The Reverse key stops the current scanning process and reverses the
original while the key is pressed.
C
A B
