5-2 Original’s Insertion Slot
The following table shows some of the most common drawing widths
and the corresponding scan-width settings in inches, mm and scanner
units:
Scanner
Units
Original Drawing Width*:
Minimum media size of scanner 6.0"/152mm
1.4 Minimum Scan Width (A5) 6.0"/152mm
2.0 A-Size (letter) and approx. A4 8.5"/216mm
2.6 B-Size (11") 11.0"/280mm
2.8 A3 (297mm) 11.9"/302mm
3.0 Approx. A3 and approx. B-Size 12.7"/323mm
3.9 A2 (420mm) 16.5"/420mm
4.0 C-Size and approx. A2 17.0"/430mm
5.2 D-Size (22") 22.0"/560mm
5.5 A1 (594mm) 23.3"/592mm
6.0 Approx. A1 and approx D-Size 25.4"/646mm
7.8 A0 Portrait (841 mm) 33.1"/840mm
8.0 E-Size and approx. A0 34.0"/862mm
11.2 E-Size Landscape 44.0”/1118mm
11.0
A0 Landscape (2A0) 46.8”/1189mm
11.8 Maximum ScanWidth of scanner 50.0"/1270mm
Maximum Media size of scanner 51.5"/1310mm
*The required setting for an original drawing can be measured, with
the original inserted into the scanner, using the ruler printed on top of
the Original Insertion Slot on the PANORAMA Monochrome Scanner.
Then, you just enter your measurement in the width setting box in
WIDEimage’s scanning setup dialogs
