3.2 Do, Do Not And CHECKS.
Do
- Check and maintain oil level in head stock and feedbox.
- Amplified pitches. Do follow guide line given for amplified pitches.
- The following table gives guideline for selection of maximum spindle
speed while cutting high range pitch threading / amplified pitches.
DO NOT
- Do not open head stock covers or change gear covers while machine
is running.
- Do not shift gears in motion.
- Do not exceed speeds of chuck or face plate beyond the specified
limit.
- Do not exceed more than 30 reversal of the motor switches per hour.
- Do not operate spindle locking lever (9) while machine spindle is
rotating.
- Do not remove chucks from threaded spindle by rotating spindle in
reverse direction.
CHECKS
- Job weight limitation. Do not load jobs weighing more than 200
kgs. Without steady rest or centre support.
- Do not start the machine at high speed with heavy jobs.
- The machine reaches peak torque 0-100 NM In 1350 series and 150
NM in 1650 series Lathe machine at 145 RPM.
- Do not exceed the rated full load current specified for the motor 3.5
Amp. For 1350 and 5.0 Amp. For 1650 series lathe.
- Sudden reversal of spindle at speed above 145 RPM is not
recommended.
PANTHER
MODEL PAGE NO.
1350 / 1650 25
Metric pitch English thread Spindle speed
2 12 280
3 8 180
4 6 112
5 5 112
6 4 71
