To open the front cover to take out the laser toner cartridge.
For placing mediums that are printed in manual feed tray.
Turn the power on or off and press this button under
Ready state to enter energy-saving mode. Press and hold
this button for more than 2s to turn the printer power off.
14 Automatic Feeder Tray
For placing mediums that are printed in auto feed tray.
15
Slide paper width deflector to adapt to paper
width.
Slide paper length deflector to adapt to paper
length.
18
For adjustment of length extension
of the tray .
Rear View
For connecting product to computer with USB cable.
3 USB Interface
4 Network Interface
For connecting product to network with network cable.
5 Power Interface
6 Rear Cover
7 Duplex Printing Unit
For connecting product to power with power cord.
For paper release when it gets jammed.
Telephone line interface, used for connection of this product
to the telephone circuit.
Extension interface, used for connection with external extension
telephone.
Note ·Printer appearance may differ because of various models and functions,
11 Front Cover
12 Manual feed tray
13 Power switch
Slide paper deflector to adapt to paper width
For paper feed at duplex printing and paper release when
paper gets jammed at duplex printing.
so the schematic diagram is only for your reference.
Paper deflector of
manual feed tray
16
Paper width deflector of
auto feed tray
17
Paper length deflector of
auto feed tray
Clip of extended tray of
auto feed tray
1
2
LINE interface (only for
machine with the fax
feature.)
EXT. interface (only for
machine with the fax
feature.)
4
