6-2
6. CONTROL PANEL
6.1. OVERVIEW OF THE CONTROL PANEL
The control panel includes a button, a multi-colored LED indicator (the LED indicator will display
red, green and orange), and a monochrome LED indicator, as shown in the gure below:
1
3
2
1 Button
2 Paper: Monochrome red LED indicator
3 Data/cartridge: multi-colored LED indicator
6.2. CONTROL PANEL'S BUTTON AND LED FUNCTIONS
1. Button Functions
By pressing the button you can fulll the following functions:
• Print a DEMO page by a long press while in idle status;
• Wake up the printer from sleep mode;
• Resume printing after a feed failure (short press);
• Resume printing after loading paper in the tray (short press);
2. Monochrome LED indicator function
The indicator will display red and an alert will sound in the case of paper
empty, paper jam, feed jam, paper mismatch, paper source and the set
paper source mismatch, etc.
