Pantum PT-L280 Series User Manual

PT-L280&PT-L380 Series User Manual
Chapter 2 Product specifications
Model PT-L280/PT-L380 Series
Printing
Print method Thermal direct/thermal transfer
Resolution
203dpi ( 8dots/mm )；300dpi ( 11.8dots/mm )
Maximum print speed
2inch/s~6inch/s；2inch/s~4inch/s
Maximum print width
104mm；106.7mm
Label print length 2286mm(90")
Consumables
Paper type
Continuous Paper, Gap Paper, Folding Paper, Black Mark
Paper, Perforated Paper, Wash Care Label
Paper winding form Outside roll
Paper width
(Label + liner)
Maximum 120mm (4.72"), minimum 20mm (0.78")
Maximum outer
diameter of built-in roll
127mm
Paper thickness
(Label + liner)
Maximum 0.254mm (10mil), minimum 0.06mm (2.36mil)
Gap height: Minimum 2mm
Paper roll core size 25.4mm-38mm
Outer diameter of
ribbon
Maximum 67mm
Ribbon length Maximum 300m
Ribbon core size 1inch(25.4mm)
Ribbon width Max.110mm, Min.30mm
Ribbon winding form Outside roll
Detection Sensor
Paper Out, Black Mark, Printhead Temperature, Printhead
Position detection
Software
Windows driver
Support WIN10 (32/64 bit), WIN8.1, Win8, WIN 7, Windows
Server 2016, WindowsServer2008 R2, Windows
Server2012 R2, Vista
MAC driver
Support Mac OS
10.13/10.12/10.11/10.10/10.9/10.8/10.7/10.6/10.5/10.4/10.3
/10.2/10.1
Linux driver Support Linux19.10, Linux18.04.5, Red Hat Linux, etc.
Software communication interface 3 ports (serial port + USB + parallel port)
Human-computer interaction
LED indicators: Running, Ribbon, Warning indicator, key:
Pause, Feed
Memory DRAM:8M FLASH:4M
Power Input: DC 24V 2.5A
Programming language TSPL
Printhead life 30km
9
