PT-L280&PT-L380 Series User Manual
4.3 Parallel port
Pin No. Signal name
1 STB
2~9 DATA1~DATA8
10 ASK
11 BUSY
12 PE
13 SEL
15 ERR
14~17 NC
18~25 GND
21
