Magellan & Spectra SP • Programming Guide
Version 4.7/4.92/5.12
System Planning | 11
Programmable Output (PGM) Planning
Wireless Repeater Planning
Zone Planning
Worksheet 4: Planning Programmable Outputs
Serial # Sticker Description Serial # Sticker Description
PGM 1 PGM 9
PGM 2 PGM 10
PGM 3 PGM 11
PGM 4 PGM 12
PGM 5 PGM 13
PGM 6 PGM 14
PGM 7 PGM 15
PGM 8 PGM 16
Worksheet 5: Planning Wireless Repeaters
Serial # Sticker Description Serial # Sticker Description
Repeater 1 Repeater 2
Worksheet 6: Planning Zones
Arming Method Arming Method
Serial # Sticker Zone # Zone Description Stay Sleep Full Serial # Sticker Zone # Zone Description Stay Sleep Full
Zone

Zone

Zone

Zone

