Installation
At the recommended height of 2.1m (7ft) to 2.7m
(9ft) ± 10%, MG-PMD85 provides full coverage
from 1.5m (5ft) to 11m (35ft) as shown in Figure 5
on page 33. The MG-PMD85 includes a
weatherproof casing so it can be installed outside.
The
MG-PMD85
has been UL evaluated at
the 2.1m (7ft) mounting height only.
Avoid placing the detector within proximity of the
following sources of interference such as direct
sunlight, reflective surfaces and moving cars.
Do not touch the sensor surface as this
could result in a detector malfunction. If
necessary, clean the sensor surface using a
soft cloth with pure alcohol.
Avoid bending, cutting or altering the
antenna or mounting the detector near or on
metal, such as aluminum siding, as this may
affect signal transmission.
After selecting the detector's location, drill or punch
out holes for the screws (Figure 4 on page 32).
