Paradox MG-PMD85 User Manual

2 Magellan MG-PMD85
The MG-PMD85 can also be mounted using
the Paradox Swivel Mount Bracket (469). The
swivel mount may allow for easier mounting. If
using the swivel mount, it is recommended that
you seal the space where the swivel mount is
connected to the back cover with some silicon
or with a rubber gasket to ensure that moisture
does not enter the detector.
The
MG-PMD85 has been UL evaluated at
the 2.1m (7ft) mounting height only.
PCB Height Adjustment
The MG-PMD85 is designed for optimal
performance at a height of 2.1m (7ft), but can be
installed lower or higher. After you have installed
the detector, ensure that the adjustable height
markings on the upper right of the PCB’s cover
inside the unit match the installation height.
For example, if the detector is installed at a
height of 2.1m (7ft), the PCB should then be
adjusted to 2.1m (7ft). Align the desired marking
(height) with the back cover’s plastic tab (Figure
1 on page 29 and Figure 2 on page 30).
If another installation height is called for, readjust
the PCB accordingly. Any PCB adjustments
should be followed by a walk-test of the
protected area. Walk-testing verifies that the
required coverage is in place.
