4 Magellan MG-PMD85
interference. Dual Edge Processing provides
better false alarm rejection if the detector is
placed near sources of interference that can
adversely affect it.
DIP switch 2 OFF = Dual Edge
DIP switch 2 ON = Single Edge (default)
DIP switches 3 and 4 are reserved for future
use.
Powering the Detector
1. Insert three “AA” batteries into the battery
holder while verifying polarity. Refer to Figure
2 on page 30.
2. Insert the battery holder into the back cover
and affix the battery cable to the battery
connector on the PCB. Refer to Figure 3 on
page 31.
After connecting the battery cable, a power-up
sequence will begin (lasting between 10 to 30
seconds). During this time, the red LED will
flash and the detector will not detect an open
zone or tamper.
Replacing the Batteries
1. Disconnect the battery cable from the battery
connector of the PCB.
2. Remove the battery holder from the back
cover and remove the old batteries.
3. Press and release the tamper switch to
ensure that the unit has powered down.
