12 Complete Installation Manual
ZONE PROGRAMMING
*The Zone Options 24-Hour Zone, Instant Zone and Follow Zone cannot be programmed on the same zone. Each zone can
be programmed with only one of these Zone Options.
SYSTEM OPTIONS
Bold = Default Setting
How Do I Program the Zones?
STEP 1: Press the [ENTER] key
STEP 2: Enter the [
INSTALLER CODE] (Default: 0000/000000)
STEP 3: Enter the 2-digit [
SECTION] representing the Zone Option (all zones Entry Delay by default)
STEP 4: Select zone(s) by pressing the corresponding key. Illuminated = Zone Option enabled for zone.
STEP 5: Press the [
ENTER] key
Section Zone Options
Inputs: Z1 Z2 Z3 Z4 Keypad Zone Fire
Zones: 1 2 3 4 5 6
Press Key
[1] [2] [3] [4] [5] [6]
[14]
Bypass Enabled
NNNN N
[15]
24Hr. Burglary* NNNN N N
[16]
Instant* NNNN N
[17]
Follow* NNNN N
[18]
Stay Zone
NNNN N
Entry Delay
Sections [15], [16] and [17] must be off for the selected zone.
Example: for an Entry Delay on zone 1, turn key [1] off in sections [15] to [17].
Force Zone
Program the zone as Bypass Enabled (section [14]).
SECTION [19]: System Options
Option
OFF ON
[1]
Zone Speed
N Slow (600ms) N Fast (20ms)
[2]
Not used
N N/A N N/A
[3]
One-touch Arming (see option [5])
N Regular Arm N Stay Arm
[4]
User Code Length
N 6 Digits N 4 Digits
[5]
One-touch Arming (see option [3])
N Disabled N Enabled
[6]
Panic Keys ([1] & [3])
N Disabled N Enabled
[7]
Auto Force Arming
N Disabled N Enabled
[8]
Stay Arming with all zones as Entry Delay zones
N Disabled N Enabled
SECTION [20]: System Options
Option
OFF ON
[1]
Reset Jumper
N Disabled N Enabled
[2]
Not used
N N/A N N/A
[3]
Alarm Relay Output
N Deactivates on Alarm N Activates on Alarm
[4]
Zone 6 is defined as
N 24Hr. Zone N Fire Zone
[5]
Not used
N N/A N N/A
[6]
Not used
N N/A N N/A
[7]
Not used
N N/A N N/A
[8]
Not used
N N/A N N/A
To Next Page
