BASIC Stamp II
SHIFTIN
Shift bits in synchronously.
usage: SHIFTIN dpin,cpin,mode,[variable{\bits},...]
Dpin is the data input.
Cpin is the clock output.
Mode is 0 for msb-first/pre-clock, 1 for lsb-first/pre-clock, 2 for msb-
first/post-clock, or 3 for lsb-first/post-clock.
Variable receives the shifted-in data.
Bits is an optional bit count. Values from 1-16 can be given; 8 is the
default.
The following symbols are defined for use with SHIFTIN:
Symbol Value
MSBPRE 0
LSBPRE 1
MSBPOST 2
LSBPOST 3
