404/406XR Series Product Manual Appendix B - Accessories & Spare Parts
43
Parker Hannifin Corporation
1140 Sandy Hill Road
Irwin, PA 15642
www.parkermotion.com
404XR Couplings
Catalog Coupling Code
Spare Part / Replacement
Part Number
Bore Diameter:
(Motor Side)
Bore Diameter:
(Table Side)
C2
002-1412-02
6.3 mm (0.25")
8 mm
C3
003-1898-53
6.3 mm (0.25")
8 mm
C4
002-1412-14
9.5 mm (0.375")
8 mm
C5
003-1898-65
9.5 mm (0.375")
8 mm
C6
002-1366-32
11.0 mm (0.43")
8 mm
C7
003-1891-95
11.0 mm (0.43")
8 mm
406XR Couplings
Catalog
Coupling
Code
Spare Part / Replacement Part
Number
Bore Diameter:
(Motor Side)
Bore Diameter: (Table Side)
Travel < 700mm
Travel ≥ 700mm
Travel < 700mm
Travel ≥ 700mm
C2
002-1412-02
002-1412-11
6.3 mm (0.25")
8 mm
12 mm
C3
003-1898-53
003-1898-55
6.3 mm (0.25")
8 mm
12 mm
C4 (w/M3 Motor
Blk.)
002-3517-40
002-1412-13
9.5 mm (0.375")
8 mm
12 mm
C4 (w/M4 or M7
Motor Blk.)
002-3517-40
002-3517-41
9.5 mm (0.375")
8 mm
12 mm
C5 (w/M3 Motor
Blk.)
003-1898-65
003-1898-21
9.5 mm (0.375")
8 mm
12 mm
C5 (w/M4 or M7
Motor Blk.)
003-1898-109
003-1898-110
9.5 mm (0.375")
8 mm
12 mm
C6
002-3517-35
002-3517-38
11.0 mm (0.43")
8 mm
12 mm
C7
003-1891-95
003-1891-105
11.0 mm (0.43")
8 mm
12 mm
C8
002-3517-34
002-3517-37
12.7 mm (0.50")
8 mm
12 mm
C9
003-1898-106
003-1898-75
12.7 mm (0.50")
8 mm
12 mm
C10
002-3517-36
002-3517-39
14.0 mm (0.55")
8 mm
12 mm
C11
003-1898-107
003-1898-81
14.0 mm (0.55")
8 mm
12 mm
