TWP/TWB200 – TWP/TWB9000
27
LEFT TOWER EXTENDED PURGE / RIGHT TOWER EXTENDED PURGE
(Blower Models Only)
If the dryer uses a blower and the Use 2% Purge Cooling setting is enabled, and the
dewpoint is above the dewpoint demand setting, then the tower will continue to regenerate
using dry air until it times out, or the dewpoint rises above the demand set point.
LEFT TOWER REPRESSURIZING / RIGHT TOWER REPRESSURIZING
Regenerating tower is waiting to pressurize before switching towers.
RIGHT DRYING - TIME REMAINING / LEFT DRYING - TIME REMAINING
Dryer still has time remaining on the drying tower and is waiting for the time to expire
before switching towers.
SWITCHING TOWERS
Towers are switching.
REGENERATING LEFT TOWER / REGENERATING RIGHT TOWER (Heatless Mode)
Dryer is in heatless backup mode and regenerating the tower.
b. Sensor Values
Inlet Pressure and Temperature
Outlet Pressure
Pre-Filter Pressure
After-Filter Pressure
Outlet Temperature
Left and Right Tank Pressures
Left and Right Exhaust Temperatures
Purge Temperature
Purge Pressure (Dry Purge models only)
Dewpoint (Optional)
Flow Meter (Optional)
c. Time
d. Model and Serial Number
e. Active Dryer Graphic
