5
Parker Hannifin Corporation
Proportional DC Valves
Series D*FC, D*1FC
Operation Manual
D_FC 5715-686 UK 07.02.2019
TAPB
A
B
Ordering code D*1FC
D*1FC
Main connector
(always on B-side of
main stage)
Parametrizing
connection
Manual override
Nominal
size
Direct.
control
valve
Command
signal
Valve
options
Function
(see catalogue)
Seal Design
series
(not required
for ordering)
Spool position
on power down
(see catalogue)
NG06
pilot
Proportional
control
Integrated
electronics
with position
feedback
Electrical
options
2)
Flow
(see catalogue)
Pilot
connection
(see catalogue)
Code Nominal size
3 NG10 / CETOP 05
4 NG16 / CETOP 07
9
1)
NG25 / CETOP 08
11 NG32 / CETOP 10
Code Valve options
0
Standard für
spool type B, E, R
8
2) 3)
Monitor switch
L
Hybrid valve 24 V
normaly closed for
spool type Z
Code Seal
N NBR
V FPM
Code Signal Function
B 0...±10 V
0...+10 V
P -> B
E
0...±20
mA
0...+20 mA
P -> B
K 0...±10 V
0...+10 V
P -> A
S 4...20 mA
12...20 mA
P -> A
1)
With enlarged connections Ø 32 mm.
2)
Not for D111FCZ*.
3)
Monitor switch for hybrid valves: code 8 includes options of code L
(24 V normally closed).
D 1 F C C
Code Electronic options
0 6 + PE
5 11 + PE
7 6 + PE with enable
