Parker Hyperchill Plus User Manual

7.5 Spare parts
11
ICEP003-005 (60Hz)
COMPONENT (Oil = O; Water = W) (7.4 / 7.5) ICEP003 ICEP005
Maintenance kits W
10 11 13 14 18 19
398H473573 398H473574
Maintenance kits O
10 11 13 14 20
398H473575
1. Electrical kit O/W -
on request
2. compressor kit O/W
1 4
KM1
398H473591 398H473592
3. fan pressure switch kit O/W
13
398H473683
4. tank kit W
16
398H471061 398H473579
5. plate type heat exchanger O/W
17
398H473583 398H473584
6. fan kit O/W
3
398H473593
refrigerant condenser O/W
2
398H114842
refrigerant filter O/W
4
398H206219
pump P30 (3 barg)
W
6
398H473596
pump P50 (5 barg)
398H473598
water manometer O/W
9
398H354031
water/oil outlet temperature sensor O/W
10
398H275233
evaporator temperature sensor O/W
11
398H275233
electronic control O/W
A1
12
398H785191
high pressure switch O/W
14
398H354121
differential water pressure switch W
18
398H354136
water level sensor W
19
398H275924
Safety thermostat O
20
on request
main switch O/W QS
on request
