Parker SensoControl User Manual

page
9
of
21
5.2
Turn
off (OFF)
O
N
O
F
F
Press
once
(
briefly
)
5.3
Turn on b
ack light
O
N
O
F
F
Press the
key (2 s)
The back light illumination will be switched off after 30 s.
5.4
MIN/MAX Display
The additional display line can be switched to MIN/MAX or FS format.
The scroll function indicates MIN/MA
X after the other.
To measure pressure peaks the MIN/MAX Function is in use. The MIN/MAX memory saves the
highest (MAX) and the lowest (MIN) reading. Switching off the instrument, the MIN/MAX memory will
be erased.
When running different pressure tests
one after another, the MIN/MAX memory should be deleted
(
RESET
) after every test cycle.
M
I
N
M
A
X
F
S
MIN/MAX and FS
value is indicated in the display
5.5
FS Full Scale Display
Displaying the upper limit of the scale (FS) is designed to increase
readability of the
bar
-
graph
function.
The upper limit of the measurement range is indicated numerically.
FS is indicated in sequence after MIN and MAX.
M
I
N
M
A
X
F
S
FS
value is indicated in the display
5.6
Erasing the
MIN/MAX
values
R
E
S
E
T
O
K
Erases
MIN/MAX
values
5.7
OFL Display
This indicates that the applied pressure
is outside given full scale range.
If the message will remain displayed,
while the
ServiceJunior
wireless
is
pressure less, please consult a Parker
Hannif
in Sales Office.

Parker SensoControl Specifications

General

Series	SensoControl
Application	Industrial Applications
Measured values	Pressure
Display	LCD
Measurement Range	0-10 bar to 0-600 bar (depending on model)
Accuracy	±0.5% FS
Housing Material	Stainless steel
Protection Class	IP65
