Parker SensoControl User Manual

page
5
of
21
3.1
Display Mode
The actual pressure (ACT) is
indicated in the display mode. The
ACT measured value is displayed in
the corresponding unit. The
MIN, MAX or FS values is indicated in the lower part of the display.
Display
Description
bar
-
graph
Graphic indication of the actual pressure.
A pressur
e peak is indicated by means of a pixel
(graduation mark).
The indicated value is refreshed at intervals of
50 ms (20 measurements/s).
ACT
Indicates the actual pressure.
The indicated value is refreshed at intervals of
300 ms (3 times/s).
MIN/MAX
Indic
ates the MIN, MAX or FS value according
to setting.
The indicated value is refreshed at intervals of
300 ms (3 times/s).
FS
Full scale range (e.g. 400 bar)
Units
Indicates the chosen unit
Battery
Indicates battery status (5 segments
)
Send or Receive M
ode
REC
REC flashes when recording measurement values
(optional data logging function)
x10
Indicated value (actual indication and MIN/MAX
indication) x10
3.2
Menu Functions
Following set ups can be done within the MENU Function:

Automatic switch off ena
ble/disabled

Selection of engineering units (bar/mbar/PSI/kPa/Mpa.)

Filter settings

REC time or REC auto function

Delete data memory
By pressing the MENU key (2
s
) the desired function appears.
Skip to next function by pressing MENU again.
Confirmation
by pressing the „OK“ key.
The
ServiceJunior
wireless
returns into the display mode.

Parker SensoControl Specifications

General

Series	SensoControl
Application	Industrial Applications
Measured values	Pressure
Display	LCD
Measurement Range	0-10 bar to 0-600 bar (depending on model)
Accuracy	±0.5% FS
Housing Material	Stainless steel
Protection Class	IP65
