Parker SensoControl User Manual

page
7
of
21
4
Connection to the hydraulics
The
ServiceJunior
wireless
is
available with male thread G1/4 (BSPP) or
7/16
-
20 UNF for the
corresponding versions (bar/PSI).
Ple
ase do not do the assembly while the ServiceJunior
wireless
is
pressurized
!
Model
SCJNP
-
xxx
-
01
-
RC
Pressure port
¼ BSPP
Adapter (M16x2)
SCA
-
1/4
-
EMA
-
3
(hex size 24 = 600 bar)
(hex size 27 = 1.000 bar) pre
-
mounted
Test Hose Adapter
(M16x2) male/male
S
CA
-
EMA
-
3/3
Other systems
Testpoint M16x1.5
SCA
-
EMA
-
3/4
Testpoint M12,65x1.5
SCA
-
EMA
-
3/2
Testpoint Pin Lock
SCA
-
EMA
-
3/1
Observe specified t
orques when fitting the ServiceJunior
wireless
The hex size of the pressure port is 27 mm
Pressure
conne
ction
Torque
7/16
-
20 UNF
35 Nm
¼ " BSPP
3
5 Nm
When fitting directly, please ensure the
ServiceJunior
wireless
can be rotated
freely.
Safety Instructions for using 1.000 bar operating range:
The delivered adapter SCA
-
1/4
-
EMA
-
3 (hex size 27) is approved up to nominal
pressure of 1,000 bar.
Please pay attention to built in test points acc. to rated nominal pressure and
specified safety factor.

Parker SensoControl Specifications

General

Series	SensoControl
Application	Industrial Applications
Measured values	Pressure
Display	LCD
Measurement Range	0-10 bar to 0-600 bar (depending on model)
Accuracy	±0.5% FS
Housing Material	Stainless steel
Protection Class	IP65
