EN | Operating manual Appendix: Technical Documents
50 WVM 45 -1450
Technical data – overview of standard dryers
Note:
For dimensions and weight of the dryer refer to the enclosed dimensional
drawing!
Nominal
capacity*
Total connected load
Weight with insulation
Desiccant per dryer
Flow rate of vacuum
pump**
permissible pressure
difference when one out-
going line
DTP -40°C
TIPO m³/h kW Kg Kg m³/h mbar
WVM 45 450 5,85 770 ~160 125 25
WVM 60 610 9,5 800 ~218 210 25
WVM 80 800 9,5 900 ~276 210 25
WVM 125 1170 14,2 1350 ~410 300 25
WVM 155 1470 19 1460 ~526 375 25
WVM 210 2050 27,5 1870 ~716 550 25
WVM 310 3050 37,5 2610 ~1058 750 25
WVM 370 3700 43,5 2900 ~1276 900 25
WVM 520 5050 73 4275 ~1762 1460 25
WVM 615 6050 73 4735 ~2090 1460 25
WVM 750 7300 86 5380 ~2540 1800 25
WVM 800 ---~ -25
WVM 1080 ---~ -25
WVM 1230 ---~ -25
WVM 1450 -- -~-25
* relative to 1 bar (abs.) and 20 °C at 7 bar operating pressure and a feed temperature
of 35 °C .
** related to a differential pressure of 100 mbar.
Fill quantities Dessicant
B1 B2
Top Silica gel Silica gel
Bottom waterproof Silica gel waterproof Silica gel
