4. Technical specifications
Technical specifications CW9T520
Electrical
requirement
Voltage 230V±10%
Frequency 50±1 Hz
HVF ＜0.02
Power input 2900W
Power output 2200W
Rated current 12A
Motor speed 2800 rpm
Thermal protector 130
Protection degree IP44
Motor working mode S6 40%
Power cable 3G1.5mm²
Technical specifications CW9T520
Machine dimension(L×W×H) (cm)
111x33x51
Machine net weight 90 kg
Min. oil capacity 5.2 Liter
Max. splitting force 9 ton ±10%
Max. splitting length 520mm
Max. splitting diameter 350mm
Min. splitting diameter 50mm
Inner hydraulic pressure 28MPa
Cylinder inner diameter 63mm
Feed time 10s
Retract time 8s
Noise emission value ≤70dB(A)
Vibration of control handle ≤2.5m/s
2
Environmental data CW9T520
Operation Altitude ≤1000m
Temperature 5~40℃
Humidity
40 ≤50%
20 ≤90%
Transportation & storage temperature (℃) -25~+50
