Any other use that is not expressly permit-
ted in this instruction manual may pose
a serious hazard to the user and result in
damage to the device. The operator or
user of the machine is responsible for any
accidents or personal injury and/or mater-
ial damage to third parties or their prop-
erty. The machine is intended to be used
by do-it-yourselfers. It was not designed
for heavy commercial use. The warranty
is void in the case of commercial use. The
manufacturer is not liable for damage
caused by improper use or incorrect oper-
ation.
The device is part of the X20VTEAM
series and can be operated with bat-
teries of the X20VTEAM series. Bat-
teries of the X20VTEAM series may
only be charged using chargers of the
X20VTEAM series.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material prop-
erly.
• Cordless Impact Driver
• Auxiliary handle
• Depth stop
• Storage case
• Carpet knife
• Measuring tape
• Ratchet screwdriver ¼"
• Screwdriver bit holder ¼"
• Accessories in storage box A
• 36 × Screw bit
2×PH0, 3×PH1, 3×PH2, 2×PH3;
2×PZ0, 3×PZ1, 3×PZ2, 2×PZ3;
H1.5, H2, H2.5, H3, 2×H4, H4.5,
2×H5, H5.5, 2×H6;
M4, M5, M6, M8
• Bit receptacle
• Accessories in storage box B
• 36 × Screw bit
T5, T6, T7, T8, 2×T10, 3×T15,
3×T20, 3×T25, T27, 2×T30, T35,
T40;
T8H, T10H, T15H, T20H, T25H,
T27H, T30H, T40H;
SL2, SL3, SL4, SL5, SL5.5, SL6,
SL6.5, SL7
• Bit receptacle
• Metal box: 18 × Drill
(wood/metal/Concrete)
3, 4, 5, 6, 8, 10mm
• Translation of the original instructions
• Rechargeable battery and charger with
instruction manual
Overview
The illustrations for the
device can be found on the
front fold-out page.
1 Drill chuck aperture
2 Keyless chuck
3 Torque adjustment ring
4 Holder for auxiliary handle
5 Function selection switch
6 Gear selector switch
7 Direction of rotation switch
8 Handle (Insulated gripping surface)
9 Belt clip
10 Battery holder
11 Button (Charge level indicator)
12 Charge level indicator
13 Battery
14 Battery release
15 LED work light
16 “Connected” indicator
17 On/Off switch
18 Loop (Auxiliary handle)

Parkside Performance PSBSAP 20-Li C3 Specifications

General

Battery Voltage	20 V
Torque	180 Nm
Impact Rate	0-3600 bpm
No-load Speed	0-2900 rpm
Chuck	1/4" Hex
Battery Type	Li-Ion
Max Torque	180 Nm
Weight	1.3 kg
