Parkside Performance PSBSAP 20-Li C3 User Manual

GB
MT
26
19 Auxiliary handle
20 Depth stop
21 Release (Carpet knife)
22 Carpet knife
23 Slider (Carpet knife)
24 Metal box (Drill)
25 Storage box (Screw bit)
26 Bit receptacle
27 Ratchet screwdriver
28 Screwdriver bit holder
29 Measuring tape
29.1 Locking button (Measuring tape)
29.2 Locking slider (Measuring tape)
29.3 Clip (Measuring tape)
30 Storage case
31 Battery charger
Fig.B
32 Screw bit
33 Drill
Fig.C
34 Handle (Auxiliary handle)
35 Locking screw of depth stop
Description of functions
Cordless impact drill screwdriver with two-
speed gearbox has 21 torque settings,
as well as one drill setting and one im-
pact setting, right/left rotation. The tool
is equipped with a keyless chuck and an
LED work light.
Please refer to the descriptions below for
information on how the operating ele-
ments work.
Technical data
Cordless Impact Driver
............................PSBSAP 20-Li C3
Rated voltage U .............................20V ⎓
Weight with battery (20V, 2Ah) ≈ 1.9kg
No-load rotation speed n
0
– Level 1 ............................... 0–630 min
−1
– Level 2 .............................0–2100 min
−1
Impact rate
–Level 1 ............................. 0-10810 min
−1
–Level 2 ............................. 0-36000 min
−1
Max. torque .................................... 64Nm
Chuck capacity ............................. ≤13mm
Max. drilling diameter
–wood ............................................. 68mm
–Concrete ........................................16mm
–steel ............................................... 13mm
Protection type .....................................IPX0
Idle
Sound pressure level (L
pA
)
...................................... 80.9 dB; K
pA
=5dB
Sound power level (L
WA
)
.....................................88.9 dB; K
WA
=5dB
Impact drilling
Sound pressure level (L
pA
)
...................................... 98.3 dB; K
pA
=5dB
Sound power level (L
WA
)
...................................106.3 dB; K
WA
=5dB
Vibration Drilling (a
h,D
)
–Main handle ...3.280m/s²; K=1.5m/s²
–Auxiliary handle
............................ 4.636m/s²; K=1.5m/s²
Vibration Impact drilling (a
h,ID
)
–Main handle .13,283m/s²; K=1.5m/s²
–Auxiliary handle
............................ 7.645m/s²; K=1.5m/s²
Battery .................................................Li-Ion
Temperature ................................... ≤50 °C
– Charging ................................4 – 40°C
– Operation ......................... −20 – 50°C
– Storage .................................. 0 – 45°C
PARKSIDE Performance Smart battery
Smart PAPS 204 A1/Smart PAPS 208 A1
–frequency band .... 2400–2483.5 MHz

Parkside Performance PSBSAP 20-Li C3 Specifications

General

Battery Voltage	20 V
Torque	180 Nm
Impact Rate	0-3600 bpm
No-load Speed	0-2900 rpm
Chuck	1/4" Hex
Battery Type	Li-Ion
Max Torque	180 Nm
Weight	1.3 kg
