Parkside PAS D5 - Replacing the Cutting Blade

41GB
Replacing the cutting blade
(Fig.K)
m CAUTION! When the saw blade[] is to be removed from or
inserted to the blade guard, do not touch the sharp cutting edge.
To avoid injury, wearing suitable protective gloves is required.
NOTE: Before carrying out any work on the product, ensure
that the rotation direction switch
[5] is in the middle position. This
prevents unintentional switching on.
 Install the cutting attachment
[] to the product.
This prevents the spindle
[] from rotating and allows the
screw
[] to be removed.
 Loosen the screw
[] in a counter‑clockwise direction by using a
PH2 or SL6 screwdriver (not included).
 Remove the screw
[] from the spindle[].
 Hold the product in an upright position. Swing it gently and
allow the cutting blade
[] to slide out slowly from the blade
guard (Fig.M).
 Insert a new cutting blade
[] into the cutting attachment[]
(Fig.N).
 Ensure the cutting blade
[] is sitting tight in the slot of the
spindle
[] (Fig.L).
 Tighten the screw
[] in a clockwise direction.
 The attachment is ready for use again.
NOTE: Replacement cutting blades [] are available from
OWIM.
