Parkside PAS D7 - Page 19

17GB/IE/NI
o Never charge the product when
the ambient temperature is below
+4 °C or above +40 °C. The storage
climate should be cool and dry and
the ambient temperature should be
between 0 °C and +50 °C.
o This product has a built-in
rechargeable battery which cannot
be replaced by the user. The removal
or replacement of the rechargeable
battery may only be carried out by
the manufacturer or his customer
service or by a similarly qualied
person in order to avoid hazards.
When disposing of the product, it
should be noted that this product
contains a rechargeable battery.
Start charging
(Fig. B)
o Connect the USB cable[] to
the USB port (Type A)
[] of the
charger
[].
o Connect the other end of the
USB cable
[] to the USB Type C
socket
[6].
o Connect the charger[] to a socket-
outlet.
o The battery status LED[3] shows the
charging status:
Battery status
LED
[3]
Charging status
Red Charging
Green Battery is charged
up
NOTE: It is normal for the handle to
warm up slightly whilst charging.
Stop charging
o Disconnect the USB cable[] from
the product.
o Disconnect the charger[] from the
socket-outlet.
 Changing rotary direction
o Push through the rotation direction
switch
[5] to set the rotary direction
(Fig. C):
Switch
pushed from
Direction
Direction
indicator
Right (b)
Tighten
screws
[2]
Left (a)
Loosen
screws
[4]
 Changing bits and magnetic
bit holder
o Pull out the bit[]. Insert another
type of bit into the bit holder
[1] or
the magnetic bit holder
[] (Fig. D).
NOTE: Screw bits are labelled
according to their dimensions and
their shape. If you are unsure, always
try the particular screw bit out to
see whether it sits in the screw head
without any free play.
 Front cover
The front cover[9] can be removed for
attaching other attachments (Fig. E).
 Choosing an attachment
T  []
Fig. F
Use L 
o Small screws
o Screwing into soft materials
H 
o Large screws
o Screwing into hard
materials
