Parkside PWBM A1 - Description of parts; Technical data

37GB/IE
 Description of parts
(Fig. A)
[1] Bit holder
[2] Direction indicator (tighten screws)
[3] Battery status LED
[4] Direction indicator (loosen screws)
[5] Rotation direction switch / Safety lock
[6] USB Type C socket
[7] Switch trigger
[8] LED work light
[9] Front cover
[] USB cable
[] Instruction manual
[] Charger *
[] USB port (Type A)
* Charger is not included. Suitable charger from article number
IAN346220_2004.
 Technical data
Cordless screwdriver
Model: HG07075
Rated voltage: 4 V (direct current)
Charging voltage: 5 V (direct current)
Maximum charging current: 1.7 A
Rechargeable battery (built-in): Lithium-lon
Number of cells: 1
Capacity: 1.5 Ah
No-load speed: n
0
= 200 min
–1
Torque (hard/soft screwing per ISO5393): Max.10Nm
Bit holder: 6.35 mm (1/4")
