4560 Mini Bench Top Reactors
Parr Instrument Company
Revision 6-28-02
HEATERS
Heaters
The 300, 450 and 600 mL Mini
Reactors are equipped with high
temperature fabric heating mantles housed
in sturdy aluminum shells. These mantles
are made in three sizes, designed to provide
uniform heat distribution to the walls and
bottoms of these vessels. They are
attached to the support rod with a clamp,
arranged so that they can be raised or
lowered on the rod as desired. Each mantle
must always be used with a vessel of the
size for which it was designed, and it must
always be fully attached to the vessel before
heat is turned on. Similarly, a short vessel
must never be heated in a deep mantle.
Without full contact with a metal wall, a
mantle will overheat and burn out.
The smaller 100 and 160 mL Mini
Reactors are heated with a high watt density
heater, which is to be clamped directly onto
the cylinder. After the vessel has been
placed in its holder, slide the heater onto the
cylinder and tighten the clamping screw
which projects from the aluminum housing.
Vessel Heaters Parts List
A2230HCEB Heater Assembly, 300mL
400W 115V
A2230HCEE Heater Assembly, 300mL
400W 230V
A2230HC2EB Heater Assembly, 450mL
590W 115V
A2230HC2EE Heater Assembly, 450mL
590W 230V
A2230HC3EB Heater Assembly, 600mL
780W 115V
A2230HC3EE Heater Assembly, 600mL
780W 230V
A2235HCEB Heater Assembly, 100/160 mL
500W 115V
A2235HCEE Heater Assembly, 100/160 mL
500W 230V
